  • Page 1 Configuration guide TDH 800 AV Input Module Model Item no. TDH 800 AV Input Module 692880 triax.com 891578A Version 08 - 2013...

  • Page 2: Table Of Contents

    Contents Contents Introduction............................... 3 System requirements ............................3 Computer minimum requirements ......................3 Static IP address ............................3 Physical connection to headend ....................... 3 Service tool ............................... 4 Overview ............................... 5 Icons................................5 Tabs ................................6 Misc. Buttons ............................. 6 Configuring AV input modules ..........................

  • Page 3: Introduction

    This document describes the configuration of the AV Input module for the TDH 800 headend. Physical installation of the module is described in the TDH 800 main unit installation guide. Physical installation of the module is described in the TDH 800 main unit installation guide.

  • Page 4: Service Tool

    Introduction Service tool 1. Open a web browser window. 2. Enter ‘http://192.168.0.100’ in the web address field. 3. Press Enter. 4. Enter the password. 5. Press the Log in button. Note: Password = ‘triax1234’ when the service tool is opened for the first time. The Keep me logged in checkbox overrides the system’s automatic time out function, which is activated after 20 minute’s inactivity.

  • Page 5: Overview

    Introduction Overview Communication icon Misc. System icon Configuration buttons Icons Indicates whether the service tool is communicating correctly with the headend unit. Green The service tool and headend are communicating correctly. The service tool and headend are NOT communicating correctly. Indicates whether the headend unit is functioning correctly.

  • Page 6: Tabs

    Introduction Tabs Accesses the various tabs used to configure the headend’s input and output modules. System The service tool’s ‘home’ window. Provides system overview information and configuration activation/control. Input Tab for configuring input modules and services. Refer to input module manuals for information. CA Modules Tab for configuring CI modules and CA cards.

  • Page 7: Configuring Av Input Modules

    The headend is running, the input module is in position, and the TDH Service Tool is connected to the headend. See the TDH 800 Headend User Guide for information on inserting the input module into the TDH 800 headend. Configuration 1.
  • Page 8 2. Select the relevant Video codec, the options are: 3. Select the relevant Audio encoding, the options are: 4. The Service name is initially set by the TDH 800 but can be modified if desired. 5. Check the Video Comb filter checkbox to ……...
  • Page 9 Input TS Rate Displays the how much data the transport stream (TS) of the input module delivers to the TDH 800 system. Input TS Lock Displays the how much data the transport stream (TS) of the input module delivers to the TDH 800 system.

  • Page 10: Modifying

    Configuration Update the software for the entire TDH 800 headend (including input/output modules) if this is not the case. 4. Press the Submit button. The output module’s first slot is now successfully configured, as shown below. 5. Press the Apply button. The following confirmation is displayed.
  • Page 11 Configuration 2. Press Yes to remove the input module. The input module is displayed in red in the Input tab. 3. Turn off the headend. 4. Physically remove the input module from the headend. 5. Restart the headend. 6. Restart the service tool. The input module will no longer be listed in the input module list.
  • Page 12 Triax Date: October 2012 Signature: triax.com/support Copyright © 2016 TRIAX. All rights reserved. The TRIAX Logo and TRIAX, TRIAX Multimedia Your ultimate connection 08-2013 are registered trademarks or trademarks of the TRIAX Company or its affiliates. All specifications in this guide are subject to change without further notice.
