M25x.75T
n
1.25 [31.8]
n
1.44 [36.5]
n
11/16-32 UN - 2B
MOTOR WIRE CONFIGURATION
PIN
1
MOTOR A+
3
+5Vdc
6
MOTOR B+
7
MOTOR A-
8
FAR LIMIT
11 MOTOR B-
12 NEAR LIMIT
13 COMMON
5.16 [131.1]
1.05 [26.7]
1.56 [39.6]
n
1.60 [40.6]
4.08 [103.5]
+
.000
n
1.312
- .001
.14 [3.4]
USED ON:
MATERIAL:
UNLESS OTHERWISE
SPECIFIED
-1 CONVERSION COATING
DIMENSIONS ARE IN INCHES
-2 PAINTING
AND INCLUDE CHEMICALLY
-3 MARKING
APPLIED OR PLATED FINISHES
-R REWORK
TOLERANCES:
SCALE:
`
DEC. .XXX
.005
FINISH:
`
DR.:
DEC. .XX
.010
`
FRACT.
1/64
CH.:
`
ANGLES
30'
APP.:
CONCENTRICITY
.003 TIR
BREAK ALL SHARP EDGES
DATE DR.:
.005 MIN. .010 MAX
CHAMFER ALL THREADS
MAX. SURF. ROUGHNESS
32
DO NOT SCALE DRAWING
~
30
TO ROOT DIAM.
REV CHANGE RECORD AND DATE CH
A
RELEASE
2.36 [59.8]
1.47 [37.3]
P/N SUFFIX DEFINITION
THE CONTENTS OF THIS
DOCUMENT ARE PROPRIETARY
TO NAVITAR, ITS USE IS
AUTHORIZED ONLY FOR
RESPONDING TO REQUEST
FOR QUOTATION OR
1:1
PERFORMANCE OF WORK FOR
NAVITAR
R. PODLENA
0.0
inch
1.0
ULTRAZOOM w/3mm FINE FOCUS &
P. BONAFEDE
COAX, DUAL 2 POSITION LS (HE)
SIZE
0.0
mm
25.0
11/22/2002
B
06/12/03
1.33 [33.8]
2.22 [56.3]
OUTLINE
ROCHESTER, NEW YORK
MOTORIZED (STEPPER) 6X
REV
1-62317
A
1
1
SHEET
OF
