Navitar 1-62314 Dimensional Drawing

FOCUS MOTOR NOT SHOWN
.50 [12.7]
n
1.093-32
n
M25x.75
1.24 [31.5]
n
1.60 [40.6]
5-PHASE MOTOR PINOUT
PIN 3 = +5Vdc
PIN13 = COMMON
PIN 8 = FAR LIMIT
PIN 12 = NEAR LIMIT
PIN 15 = MOTOR 1
PIN 5 = MOTOR 2
PIN 10 = MOTOR 3
PIN 4 = MOTOR 4
PIN 14 = MOTOR 5
3.31 [84.1] .80 [20.3]
4.44 [112.6]
.05 [1.2]
5.16 [131.0]
15 PIN HIGH DENSITY
D-SUB
.38 [9.5]
.75 [19.1]
(4) x 4-40 UNC - 2B
.32 [8.3]
.72 [18.4]
n
1.312-.001
USED ON:
MATERIAL:
UNLESS OTHERWISE
SPECIFIED
DIMENSIONS ARE IN INCHES
AND INCLUDE CHEMICALLY
APPLIED OR PLATED FINISHES
TOLERANCES:
DEC. .XXX
FINISH:
DEC. .XX
FRACT.
ANGLES
CONCENTRICITY
BREAK ALL SHARP EDGES
.005 MIN. .010 MAX
CHAMFER ALL THREADS
MAX. SURF. ROUGHNESS
~
30 TO ROOT DIAM.
REV CHANGE RECORD AND DATE CH
3.07 [77.9]
3.08 [78.2]
2.19 [55.7]
P/N SUFFIX DEFINITION THE CONTENTS OF THIS
DOCUMENT ARE PROPRIETARY
-1 CONVERSION COATING
TO NAVITAR, ITS USE IS
-2 PAINTING
AUTHORIZED ONLY FOR
-3 MARKING
RESPONDING TO REQUEST
-R REWORK
FOR QUOTATION OR
1:1
SCALE: PERFORMANCE OF WORK FOR
`
.005
NAVITAR
`
DR.: R. PODLENA
.010
0.0 inch
`
1/64 CH.: P. BONAFEDE
`
30'
APP.:
.003 TIR
0.0 mm 25.0
11/22/2002
DATE DR.:
32
DO NOT SCALE DRAWING
2.19 [55.7] 3.44 [87.5]
OUTLINE
ROCHESTER, NEW YORK
MOTORIZED (5PH VEXTA STEPPER)
1.0
6x ZOOM & 12mm FF, DUAL 2
POSITION LS (HE)
SIZE
REV
1-62314
A
B
1 1
SHEET OF
