n
1.60 [40.6]
.60 [15.2]
M25x.75T
n
1.44 [36.5]
.05 [1.2]
5.26 [133.6]
.72 [18.4]
n
1.312-.001
USED ON:
MATERIAL:
P/N SUFFIX DEFINITION
UNLESS OTHERWISE
SPECIFIED
-1 CONVERSION COATING
DIMENSIONS ARE IN INCHES
-2 PAINTING
AND INCLUDE CHEMICALLY
-3 MARKING
APPLIED OR PLATED FINISHES
-R REWORK
TOLERANCES:
SCALE:
`
DEC. .XXX
.005
FINISH:
`
DR.:
DEC. .XX
.010
`
FRACT.
1/64
CH.:
`
ANGLES
30'
APP.:
CONCENTRICITY
.003 TIR
BREAK ALL SHARP EDGES
DATE DR.:
.005 MIN. .010 MAX
CHAMFER ALL THREADS
MAX. SURF. ROUGHNESS
32
DO NOT SCALE DRAWING
~
30
TO ROOT DIAM.
REV CHANGE RECORD AND DATE CH
A
RELEASE
3.07 [78.0]
2.19 [55.7] 3.44 [87.3]
2.19 [55.7]
3.08 [78.3]
THE CONTENTS OF THIS
DOCUMENT ARE PROPRIETARY
TO NAVITAR, ITS USE IS
AUTHORIZED ONLY FOR
RESPONDING TO REQUEST
ROCHESTER, NEW YORK
FOR QUOTATION OR
1:1
PERFORMANCE OF WORK FOR
NAVITAR
MOTORIZED (5PH VEXTA STEPPER)
R. PODLENA
0.0
inch
1.0
6x ULTRAZOOM & 12mm FF, DUAL 2
P. BONAFEDE
SIZE
0.0
mm
25.0
11/22/2002
B
06/16/03
n
1.78 [45.2]
GEAR O.D.
OUTLINE
POSITION LS (HE)
REV
1-62312
A
1
1
SHEET
OF
