n
1.78 [45.2]
(GEAR O.D.)
.50 [12.7]
1.093 - 32T
n
1.24 [31.5]
M25x.75T
n
1.60 [40.6]
5.19 [131.8]
.76 [19.2]
n
.43 [10.9]
n
1.60 [40.6]
USED ON:
MATERIAL:
FINISH:
CHAMFER ALL THREADS
30
+
.000
1.312
- .001
P/N SUFFIX DEFINITION
UNLESS OTHERWISE
SPECIFIED
-1 CONVERSION COATING
DIMENSIONS ARE IN INCHES
-2 PAINTING
AND INCLUDE CHEMICALLY
-3 MARKING
APPLIED OR PLATED FINISHES
-R REWORK
TOLERANCES:
SCALE:
`
DEC. .XXX
.005
`
DR.:
R. PODLENA
DEC. .XX
.010
`
FRACT.
1/64
CH.:
P. BONAFEDE
`
ANGLES
30'
APP.:
P. BONAFEDE
CONCENTRICITY
.003 TIR
BREAK ALL SHARP EDGES
DATE DR.:
.005 MIN. .010 MAX
MAX. SURF. ROUGHNESS
32
DO NOT SCALE DRAWING
~
TO ROOT DIAM.
REV CHANGE RECORD AND DATE CH
A
RELEASE
2.36 [59.9]
1.47 [37.3]
1.33 [33.8]
OUTLINE
THE CONTENTS OF THIS
DOCUMENT ARE PROPRIETARY
TO NAVITAR, ITS USE IS
AUTHORIZED ONLY FOR
RESPONDING TO REQUEST
ROCHESTER, NEW YORK
FOR QUOTATION OR
1:1
PERFORMANCE OF WORK FOR
NAVITAR
MOTORIZED (ENCODED) 6x ZOOM &
0.0
inch
1.0
12mm FF, DUAL 2 POSITION LS (HE)
SIZE
0.0
mm
25.0
8/9/2002
B
06/12/03
2.22 [56.4]
REV
1-62310
A
1
1
SHEET
OF
