Navitar 1-62308 Dimensional Drawing

n
1.25 [31.8]
M25x.75T
n
1.60 [40.6]
5.29 [134.3]
.43 [10.9]
n
1.78 [45.2]
USED ON:
MATERIAL:
FINISH:
CHAMFER ALL THREADS
~
30
.76 [19.2]
+ .000
n
1.312
- .001
P/N SUFFIX DEFINITION
UNLESS OTHERWISE
SPECIFIED
-1 CONVERSION COATING
DIMENSIONS ARE IN INCHES -2 PAINTING
AND INCLUDE CHEMICALLY
-3 MARKING
APPLIED OR PLATED FINISHES
-R REWORK
TOLERANCES:
SCALE:
`
DEC. .XXX .005
`
DR.: R. PODLENA
DEC. .XX .010
`
FRACT. 1/64 CH.: P. BONAFEDE
`
ANGLES 30'
APP.:
CONCENTRICITY .003 TIR
BREAK ALL SHARP EDGES
DATE DR.:
.005 MIN. .010 MAX
MAX. SURF. ROUGHNESS 32
DO NOT SCALE DRAWING
TO ROOT DIAM.
REV CHANGE RECORD AND DATE CH
A
RELEASE
2.36 [59.9]
1.47 [37.3]
1.33 [33.8]
OUTLINE
THE CONTENTS OF THIS
DOCUMENT ARE PROPRIETARY
TO NAVITAR, ITS USE IS
AUTHORIZED ONLY FOR
RESPONDING TO REQUEST
ROCHESTER, NEW YORK
FOR QUOTATION OR
1:1
PERFORMANCE OF WORK FOR
NAVITAR
MOTORIZED (ENCODED) 6x
0.0 inch 1.0
ULTRAZOOM & 12mm FF, DUAL 2
SIZE
0.0 mm 25.0
11/22/2002
B
06/12/03
2.22 [56.4]
POSITION LS (HE)
REV
1-62308
A
1 1
SHEET OF
