.44 [11.1]
n
1.24 [31.5]
M25x.75T
1.093 - 32T
n
1.44 [36.5]
MOTOR WIRE CONFIGURATION
PIN
1
MOTOR A+
3
+5Vdc
6
MOTOR B+
7
MOTOR A-
8
FAR LIMIT
11 MOTOR B-
12 NEAR LIMIT
13 COMMON
5.09 [129.3]
.14 [3.4]
n
1.60 [40.6]
11/16-32 UN - 2B
n
1.60 [40.6]
4.08 [103.5]
USED ON:
MATERIAL:
FINISH:
CHAMFER ALL THREADS
~
30
+
.000
n
1.312
- .001
1.05 [26.7]
P/N SUFFIX DEFINITION
UNLESS OTHERWISE
SPECIFIED
-1 CONVERSION COATING
DIMENSIONS ARE IN INCHES
-2 PAINTING
AND INCLUDE CHEMICALLY
-3 MARKING
APPLIED OR PLATED FINISHES
-R REWORK
TOLERANCES:
SCALE:
`
DEC. .XXX
.005
`
DR.:
R. PODLENA
DEC. .XX
.010
`
FRACT.
1/64
CH.:
P. BONAFEDE
`
ANGLES
30'
APP.:
CONCENTRICITY
.003 TIR
BREAK ALL SHARP EDGES
DATE DR.:
.005 MIN. .010 MAX
MAX. SURF. ROUGHNESS
32
DO NOT SCALE DRAWING
TO ROOT DIAM.
REV CHANGE RECORD AND DATE CH
A
RELEASE
2.36 [59.8]
1.47 [37.3]
1.33 [33.8]
OUTLINE
THE CONTENTS OF THIS
DOCUMENT ARE PROPRIETARY
TO NAVITAR, ITS USE IS
AUTHORIZED ONLY FOR
RESPONDING TO REQUEST
ROCHESTER, NEW YORK
FOR QUOTATION OR
1:1
PERFORMANCE OF WORK FOR
NAVITAR
MOTORIZED (STEPPER) 6X w/3mm
0.0
inch
1.0
FINE FOCUS & COAX, DUAL 2
SIZE
0.0
mm
25.0
11/22/2002
B
06/12/03
2.22 [56.3]
POSITION LS (HE)
REV
1-62319
A
1
1
SHEET
OF
