.44 [11.1]
1.093 - 32T
n
1.24 [31.5]
M25x.75T
n
1.44 [36.5]
4.08 [103.5]
.05 [1.3]
5.68 [144.3]
USED ON:
MATERIAL:
FINISH:
CHAMFER ALL THREADS
~
30
TO ROOT DIAM.
.73 [18.4]
n
1.312-.001
P/N SUFFIX DEFINITION
UNLESS OTHERWISE
SPECIFIED
-1 CONVERSION COATING
DIMENSIONS ARE IN INCHES
-2 PAINTING
AND INCLUDE CHEMICALLY
-3 MARKING
APPLIED OR PLATED FINISHES
-R REWORK
TOLERANCES:
1:1
SCALE:
`
DEC. .XXX
.005
`
DR.:
R. PODLENA
DEC. .XX
.010
`
FRACT.
1/64
CH.:
P. BONAFEDE
`
ANGLES
30'
APP.:
CONCENTRICITY
.003 TIR
BREAK ALL SHARP EDGES
11/11/2002
DATE DR.:
.005 MIN. .010 MAX
MAX. SURF. ROUGHNESS
32
DO NOT SCALE DRAWING
REV CHANGE RECORD AND DATE CH
A
RELEASE
3.07 [78.0]
2.19 [55.7]
3.45 [87.5]
n
1.60 [40.6]
SLEEVE O.D.
n
1.78 [45.2]
GEAR O.D.
2.19 [55.7]
3.08 [78.3]
OUTLINE
THE CONTENTS OF THIS
DOCUMENT ARE PROPRIETARY
TO NAVITAR, ITS USE IS
AUTHORIZED ONLY FOR
RESPONDING TO REQUEST
ROCHESTER, NEW YORK
FOR QUOTATION OR
PERFORMANCE OF WORK FOR
NAVITAR
MOTORIZED (5PH VEXTA) 6X ZOOM
0.0
inch
1.0
& 3mm FF w/COAX, DUAL 2
POSITION LS (HE)
SIZE
0.0
mm
25.0
1-62315
B
1
SHEET
06/16/03
REV
A
1
OF
