Assembly Instructions
Adjusting the Radius
7
5
For disassembly, reverse steps 1-6.
Ensure the radius adjustment pin is fully engaged before use.
Release the jib retaining strap and rotate jib
The operator can choose the most suitable radius
assembly outwards
for use, by inserting the pin in the adjustment
plate
6
The decal specifies the reach values with
the upper value stating the outer shackle
position and the lower value stating the
inner shackle position
Notes
Variants &
Options.
PORTADAVIT
PORTADAVIT
QUANTUM
QUANTUM
19
19
