Summary of Contents for Daikin VRV FXHA32AVEB8
- Page 1 Installer and user reference guide VRV system air conditioner FXHA32AVEB8 FXHA50AVEB8 FXHA63AVEB8 FXHA100AVEB8...
-
Page 2: Table Of Contents
Table of contents Table of contents 1 About the documentation About this document ..............................Meaning of warnings and symbols..........................2 General safety precautions For the installer ................................2.1.1 General ................................2.1.2 Installation site ............................... 2.1.3 Refrigerant — in case of R410A or R32......................2.1.4 Electrical ................................. - Page 3 Table of contents For the installer 14 About the box 14.1 Indoor unit ..................................44 14.1.1 To unpack and handle the unit ........................44 14.1.2 To remove the accessories from the indoor unit ..................45 15 About the units and options 15.1 Identification ...................................
-
Page 4: About The Documentation
The original documentation is written in English. All other languages are translations. Technical engineering data ▪ A subset of the latest technical data is available on the regional Daikin website (publicly accessible). ▪ The full set of latest technical data is available on the Daikin Business Portal (authentication required). -
Page 5: Meaning Of Warnings And Symbols
About the documentation 1.2 Meaning of warnings and symbols DANGER Indicates a situation that results in death or serious injury. DANGER: RISK OF ELECTROCUTION Indicates a situation that could result in electrocution. DANGER: RISK OF BURNING/SCALDING Indicates a situation that could result in burning/scalding because of extreme hot or cold temperatures. - Page 6 About the documentation Symbol Explanation Indicates a table title or a reference to it. Example: " 1–3 Table title" means "Table 3 in chapter 1". FXHA-A Installer and user reference guide VRV system air conditioner 4P673749-1A – 2022.11...
-
Page 7: General Safety Precautions
WARNING Improper installation or attachment of equipment or accessories could result in electrical shock, short-circuit, leaks, fire or other damage to the equipment. ONLY use accessories, optional equipment and spare parts made or approved by Daikin unless otherwise specified. WARNING Make sure installation, testing and applied materials comply with applicable legislation (on top of the instructions described in the Daikin documentation). -
Page 8: Installation Site
General safety precautions Also, at least, following information MUST be provided at an accessible place at the product: ▪ Instructions for shutting down the system in case of an emergency ▪ Name and address of fire department, police and hospital ▪... - Page 9 General safety precautions WARNING ALWAYS recover the refrigerant. Do NOT release them directly into the environment. Use a vacuum pump to evacuate the installation. WARNING Make sure there is no oxygen in the system. Refrigerant may ONLY be charged after performing the leak test and the vacuum drying.
-
Page 10: Electrical
General safety precautions ▪ Charge the refrigerant in liquid form. Adding it in gas form may prevent normal operation. CAUTION When the refrigerant charging procedure is done or when pausing, close the valve of the refrigerant tank immediately. If the valve is NOT closed immediately, remaining pressure might charge additional refrigerant. - Page 11 General safety precautions CAUTION ▪ When connecting the power supply: connect the earth cable first, before making the current-carrying connections. ▪ When disconnecting the power supply: disconnect the current-carrying cables first, before separating the earth connection. ▪ The length of the conductors between the power supply stress relief and the terminal block itself MUST be as such that the current-carrying wires are tautened before the earth wire is in case the power supply is pulled loose from the stress relief.
-
Page 12: Specific Installer Safety Instructions
WARNING Make sure installation, servicing, maintenance, repair and applied materials follow the instructions from Daikin (including all documents listed in “Documentation set”) and, in addition, comply with applicable legislation and are performed by qualified persons only. In Europe and areas where IEC standards apply, EN/IEC 60335-2-40 is the applicable standard. - Page 13 Specific installer safety instructions CAUTION Install the refrigerant piping or components in a position where they are unlikely to be exposed to any substance which may corrode components containing refrigerant, unless the components are constructed of materials that are inherently resistant to corrosion or are suitably protected against corrosion.
-
Page 14: Instructions For Equipment Using R32 Refrigerant
WARNING Make sure installation, servicing, maintenance and repair comply with instructions from Daikin and with applicable legislation and are executed ONLY by authorised persons. WARNING If one or more rooms are connected to the unit using a duct system, make sure: ▪... -
Page 15: Installation Space Requirements
Specific installer safety instructions WARNING ▪ Take precautions to avoid excessive vibration or pulsation to refrigeration piping. ▪ Protect the protection devices, piping and fittings as much as possible against adverse environmental effects. ▪ Provide space for expansion and contraction of long runs of piping. ▪... -
Page 16: For The User
For the user FXHA-A Installer and user reference guide VRV system air conditioner 4P673749-1A – 2022.11... -
Page 17: User Safety Instructions
User safety instructions 4 User safety instructions Always observe the following safety instructions and regulations. 4.1 General WARNING If you are NOT sure how to operate the unit, contact your installer. WARNING This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning... -
Page 18: Instructions For Safe Operation
User safety instructions ▪ Units are marked with the following symbol: This means that electrical and electronic products may NOT be mixed with unsorted household waste. Do NOT try to dismantle the system yourself: dismantling the system, treatment of the refrigerant, of oil and of other parts MUST be done by an authorised installer and MUST comply with applicable legislation. - Page 19 User safety instructions CAUTION ▪ NEVER touch the internal parts of the controller. ▪ Do NOT remove the front panel. Some parts inside are dangerous to touch and appliance problems may happen. For checking and adjusting the internal parts, contact your dealer. WARNING This unit contains electrical and hot parts.
- Page 20 User safety instructions WARNING Keep any required ventilation openings clear of obstructions. Maintenance and service (see "10 Maintenance and service" [ 31]) CAUTION: Pay attention to the fan! It is dangerous to inspect the unit while the fan is running. Make sure to turn OFF the main switch before executing any maintenance task.
- Page 21 User safety instructions DANGER: RISK OF ELECTROCUTION Disconnect the power supply for more than 10 minutes, and measure the voltage at the terminals of main circuit capacitors or electrical components before servicing. The voltage MUST be less than 50 V DC before you can touch electrical components.
- Page 22 User safety instructions WARNING ▪ The refrigerant inside the unit is mildly flammable, but normally does NOT leak. If the refrigerant leaks in the room and comes in contact with fire from a burner, a heater, or a cooker, this may result in fire, or the formation of a harmful gas.
-
Page 23: About The System
About the system 5 About the system WARNING ▪ Do NOT modify, disassemble, remove, reinstall or repair the unit yourself as incorrect dismantling or installation may cause an electrical shock or fire. Contact your dealer. ▪ In case of accidental refrigerant leaks, make sure there are no naked flames. The refrigerant itself is entirely safe, non-toxic and mildly flammable, but it will generate toxic gas when it accidentally leaks into a room where combustible air from fan heaters, gas cookers, etc. -
Page 24: Information Requirements For Fan Coil Units
Total electric power input elec Sound power level (cooling) dB(A) Sound power level (heating) dB(A) Contact details: DAIKIN INDUSTRIES CZECH REPUBLIC s.r.o. U Nové Hospody 1/1155, 301 00 Plzeň Skvrňany, Czech Republic FXHA32 0.033 FXHA50 0.037 FXHA63 0.051 FXHA100 12.5... -
Page 25: User Interface
User interface 6 User interface CAUTION ▪ NEVER touch the internal parts of the controller. ▪ Do NOT remove the front panel. Some parts inside are dangerous to touch and appliance problems may happen. For checking and adjusting the internal parts, contact your dealer. -
Page 26: Before Operation
Before operation 7 Before operation WARNING This unit contains electrical and hot parts. WARNING Before operating the unit, be sure the installation has been carried out correctly by an installer. CAUTION It is unhealthy to expose your body to the air flow for a long time. CAUTION To avoid oxygen deficiency, ventilate the room sufficiently if equipment with burner is used together with the system. -
Page 27: Operation
Operation 8 Operation 8.1 Operation range INFORMATION For the operation limits see the technical data of the connected outdoor unit. 8.2 About operation modes INFORMATION Depending on the installed system, some operation modes will not be available. ▪ The air flow rate may adjust itself depending on the room temperature or the fan may stop immediately. -
Page 28: Special Heating Operation Modes
Operation 8.2.2 Special heating operation modes Operation Description Defrost To prevent a loss of heating capacity due to frost accumulation in the outdoor unit, the system will automatically switch to defrost operation. During defrost operation, the indoor unit fan will stop operation, and the following icon will appear on the home screen: The system will resume normal operation after approximately 6... -
Page 29: To Operate The System
Operation Direction Display Swing. The indoor unit alternates between the 5 positions. Note: The recommended position of the horizontal blades (flaps) varies according to the operation mode. a Cooling operation b Heating operation WARNING NEVER touch the air outlet or the horizontal blades while the swing flap is in operation. -
Page 30: Energy Saving And Optimum Operation
Energy saving and optimum operation 9 Energy saving and optimum operation CAUTION NEVER expose little children, plants or animals directly to the airflow. NOTICE Do NOT place objects below the indoor and/or outdoor unit that may get wet. Otherwise condensation on the unit or refrigerant pipes, air filter dirt or drain blockage may cause dripping, and objects under the unit may get dirty or damaged. -
Page 31: Maintenance And Service
Maintenance and service 10 Maintenance and service 10.1 Precautions for maintenance and service NOTICE Maintenance MUST be done by an authorised installer or service agent. We recommend performing maintenance at least once a year. However, applicable legislation might require shorter maintenance intervals. CAUTION: Pay attention to the fan! It is dangerous to inspect the unit while the fan is running. -
Page 32: Cleaning The Unit Exterior, Air Filter And Suction Grille
Maintenance and service NOTICE When cleaning the heat exchanger, make sure to remove the electronic components above it. Water or detergent might deteriorate the insulation of electronic components and result in burnout of these components. DANGER: RISK OF ELECTROCUTION Disconnect the power supply for more than 10 minutes, and measure the voltage at the terminals of main circuit capacitors or electrical components before servicing. -
Page 33: To Clean The Suction Grille
Maintenance and service ▪ Depending on the settings, the user interface can display the "Time to clean filter" notification. Clean the air filter when the notification is displayed. ▪ If the dirt becomes impossible to clean, change the air filter (= optional equipment). -
Page 34: Maintenance Before A Long Stop Period
Maintenance and service a Knob 2 Remove the suction grille. While keeping the suction grille open, unhook the straps from the indoor unit. Then remove the clips (2 for class 32, 3 for class 50~100) holding the suction grille. a Strap a Clip 3 Remove the air filter. -
Page 35: Maintenance After A Long Stop Period
Maintenance and service 10.4 Maintenance after a long stop period E.g., at the beginning of the season. ▪ Check and remove everything that might be blocking inlet and outlet vents of indoor units and outdoor units. ▪ Clean air filters and casings of indoor units (see "10.2 Cleaning the unit exterior, air filter and suction grille" [... -
Page 36: About The Refrigerant Leakage Sensor
Maintenance and service 10.5.1 About the refrigerant leakage sensor WARNING The R32 refrigerant leakage sensor must be replaced after every detection or at the end of its lifetime. ONLY authorised persons may replace the sensor. NOTICE The R32 refrigerant leakage sensor is a semiconductor detector which may incorrectly detect substances other than R32 refrigerant. - Page 37 Maintenance and service INFORMATION To stop the alarm of the user interface, see the reference guide of the user interface. FXHA-A Installer and user reference guide VRV system air conditioner 4P673749-1A – 2022.11...
-
Page 38: Troubleshooting
Troubleshooting 11 Troubleshooting If one of the following malfunctions occur, take the measures shown below and contact your dealer. WARNING Stop operation and shut OFF the power if anything unusual occurs (burning smells etc.). Leaving the unit running under such circumstances may cause breakage, electrical shock or fire. -
Page 39: Symptoms That Are Not System Malfunctions
Troubleshooting Malfunction Measure The system operates but ▪ Check if air inlet or outlet of outdoor or indoor cooling or heating is unit is not blocked by obstacles. Remove any insufficient. obstacles and make sure the air can flow freely. ▪... -
Page 40: Symptom: White Mist Comes Out Of A Unit (Indoor Unit)
Troubleshooting 11.1.4 Symptom: White mist comes out of a unit (Indoor unit) ▪ When humidity is high during cooling operation. If the interior of an indoor unit is extremely contaminated, the temperature distribution inside a room becomes uneven. It is necessary to clean the interior of the indoor unit. Ask your dealer for details on cleaning the unit. -
Page 41: Relocation
Relocation 12 Relocation Contact your dealer to remove and reinstall the entire unit. Moving units requires technical expertise. FXHA-A Installer and user reference guide VRV system air conditioner 4P673749-1A – 2022.11... -
Page 42: Disposal
Disposal 13 Disposal NOTICE Do NOT try to dismantle the system yourself: dismantling of the system, treatment of the refrigerant, oil and other parts MUST comply with applicable legislation. Units MUST be treated at a specialised treatment facility for reuse, recycling and recovery. FXHA-A Installer and user reference guide VRV system air conditioner... -
Page 43: For The Installer
For the installer FXHA-A Installer and user reference guide VRV system air conditioner 4P673749-1A – 2022.11... -
Page 44: About The Box
About the box 14 About the box Keep the following in mind: ▪ At delivery, the unit MUST be checked for damage and completeness. Any damage or missing parts MUST be reported immediately to the claims agent of the carrier. ▪... -
Page 45: To Remove The Accessories From The Indoor Unit
About the box FXHA50~100 2 Lift the unit; make sure not to damage the resin side panel, the discharge horizontal blade and the air outlet. ▪ Do NOT lift the unit by the reinforcing plates; if the reinforcing plates are bent, this may cause noise during operation. - Page 46 About the box 1× 1× 1× 1× 1× 8× 7× 1× 4× 1× 1× 2× 2× 1× 1× a General safety precautions b Indoor unit installation and operation manual c Paper pattern for installation (part of the packing) d Drain hose e Metal clamp f Washer for hanger bracket g Tie wraps...
-
Page 47: About The Units And Options
About the units and options 15 About the units and options In this chapter 15.1 Identification................................... 15.1.1 Identification label: Indoor unit ..........................15.2 About the indoor unit................................15.3 System layout..................................15.4 Combining units and options..............................15.4.1 Possible options for the indoor unit ........................15.1 Identification NOTICE When installing or servicing several units at the same time, make sure NOT to switch... -
Page 48: Combining Units And Options
About the units and options a Indoor unit b Outdoor unit c User interface d Suction air e Discharge air f Refrigerant piping + transmission cable g Drain pipe h Suction grille and air filter 15.4 Combining units and options INFORMATION Certain options may NOT be available in your country. - Page 49 About the units and options ▪ An additional Installation box for the optional output PCB is required; see the option list of the indoor unit. For installation of the installation box, refer to the manual of the installation box. The wiring between the main PCB and the optional output PCB must be led together with the transmission cable;...
-
Page 50: Unit Installation
Unit installation 16 Unit installation In this chapter 16.1 Preparing the installation site ..............................16.1.1 Installation site requirements of the indoor unit ....................16.2 Mounting the indoor unit............................... 16.2.1 Guidelines when installing the indoor unit......................16.2.2 Guidelines when installing the drain piping ......................16.1 Preparing the installation site Choose an installation location with sufficient space to transport the unit in and out of the site. - Page 51 Unit installation CAUTION Appliance NOT accessible to the general public, install it in a secured area, protected from easy access. This unit, both indoor and outdoor, is suitable for installation in a commercial and light industrial environment. WARNING Keep any required ventilation openings clear of obstructions. NOTICE If the equipment is installed closer than 30 ...
-
Page 52: Mounting The Indoor Unit
Unit installation ≥30 ≥30 (mm) Minimum and maximum distance to the floor: Minimum: 2.5 m to avoid accidental touching. Maximum: Depends on the capacity class. See "21.1 Field setting" [ 77]. (mm) a Discharge b Suction c Obstacle d Floor INFORMATION Some options may require additional service space. Sees the installation manual of the used option before installation. - Page 53 Unit installation ▪ Suspension bolts and unit. Use M8~M10 suspension bolts for installation. Attach the hanger bracket to the suspension bolt. Fix it securely using a nut and washer on the top and bottom of the hanger bracket. Front view (mm) Top (ceiling) view 4×...
- Page 54 Unit installation ≤ 1° ≤ 1° ≤ 1° A Drain piping tilted to the right, or to the right and back B Drain piping tilted to the left, or to the left and back NOTICE Do NOT install the unit tilted in other ways than specified. Possible consequence: If the unit is tilted against the direction of the condensate flow (the drain piping side is raised), the float switch might malfunction and cause water to drip.
- Page 55 Unit installation To mount the indoor unit 1 Open the knockout hole at the wiring inlet at the rear or the top of the unit, and install the resin bushing (accessory). a Resin bushing (accessory) b Knockout hole (for leading in from the top) c Knockout hole (for leading in from the rear) 2 Remove the hanger bracket.
-
Page 56: Guidelines When Installing The Drain Piping
Unit installation a Hanger bracket b Hanger bracket installation bolt (M8) c Hanger bracket fixing screw (M5) d Reinforcing plate 5 Install the hanger bracket fixing screws (M5) on both sides back (2 screws in total). 6 Fully tighten all hanger bracket installation bolts (M8) (4 screws in total). 7 Make sure the unit is level. - Page 57 Unit installation a Left drain piping b Rear left drain piping c Rear right drain piping d Right drain piping Rear left or left drain piping 1 Remove the protective grille (32 class: 7 screws, 50+63 class: 11 screws, 100 class: 10 screws).
- Page 58 Unit installation a Rear right drain piping b Rear piping pipe port cover Right drain piping 1 Remove the reinforcing plate from the right side and put back the screw in the original position on the indoor unit. 2 Remove the rectangular part from the decoration side panel (when installing only drain piping on the right side, remove the round part only).
- Page 59 Unit installation To check for water leaks Make sure the unit is level in accordance with the instructions in "16.2.1 Guidelines when installing the indoor unit" [ 52]. Gradually pour approximately 1 l of water through the air discharge outlet, and check for leaks. (mm) a Air outlet b Plastic water container with tube length ≥100 mm...
-
Page 60: Piping Installation
Piping installation 17 Piping installation In this chapter 17.1 Preparing refrigerant piping ..............................17.1.1 Refrigerant piping requirements ........................... 17.1.2 Refrigerant piping insulation..........................17.2 Connecting the refrigerant piping............................17.2.1 About connecting the refrigerant piping....................... 17.2.2 Precautions when connecting the refrigerant piping.................... 17.2.3 Guidelines when connecting the refrigerant piping.................... -
Page 61: Refrigerant Piping Insulation
Piping installation Outer diameter (Ø) Temper grade Thickness (t) Ø 6.4 mm (1/4") Annealed (O) ≥0.8 mm 9.5 mm (3/8") 12.7 mm (1/2") 15.9 mm (5/8") Depending on the applicable legislation and the maximum working pressure of the unit (see "PS High" on the unit name plate), larger piping thickness might be required. 17.1.2 Refrigerant piping insulation ▪... -
Page 62: Precautions When Connecting The Refrigerant Piping
Piping installation 17.2.2 Precautions when connecting the refrigerant piping DANGER: RISK OF BURNING/SCALDING NOTICE ▪ Use the flare nut fixed to the main unit. ▪ To prevent gas leakage, apply refrigeration oil only to the inside of the flare. Use refrigeration oil for R32 (Example: FW68DA). -
Page 63: Guidelines When Connecting The Refrigerant Piping
Piping installation 17.2.3 Guidelines when connecting the refrigerant piping Take the following guidelines into account when connecting pipes: ▪ Coat the flare inner surface with ether oil or ester oil when connecting a flare nut. Tighten 3 or 4 turns by hand, before tightening firmly. ▪... -
Page 64: To Connect The Refrigerant Piping To The Indoor Unit
Piping installation 3 Remove the flare nut from the stop valve and put the flare nut on the pipe. 4 Flare the pipe. Set exactly at the position as shown in the following figure. Flare tool for R32 Conventional flare tool (clutch type) Clutch type Wing nut type... - Page 65 Piping installation a Rear refrigerant piping b Rear piping pipe port cover 2 Run the field supply pipes through the cut out holes. 3 After the drain and refrigerant piping is finished, install the pipe port cover back. Run all the cables (except cable of expansion valve) through the clamp of the pipe port cover and fix.
- Page 66 Piping installation a Round part b Rectangular part of the decoration side panel c Decoration side panel d Screw e Reinforcing plate f Right refrigerant piping 4 After the drain and refrigerant piping is finished, install the reinforcing plate (optional step) and the decoration side panel back. a Screw b Reinforcing plate c Decoration side panel...
- Page 67 Piping installation NOTICE Make sure to insulate all refrigerant piping. Any exposed piping might cause condensation. FXHA-A Installer and user reference guide VRV system air conditioner 4P673749-1A – 2022.11...
-
Page 68: Electrical Installation
Electrical installation 18 Electrical installation In this chapter 18.1 About connecting the electrical wiring ..........................18.1.1 Precautions when connecting the electrical wiring ....................18.1.2 Guidelines when connecting the electrical wiring ....................18.1.3 Specifications of standard wiring components ..................... 18.2 To connect the electrical wiring to the indoor unit ....................... 18.1 About connecting the electrical wiring Typical workflow Connecting the electrical wiring typically consists of the following stages:... -
Page 69: Guidelines When Connecting The Electrical Wiring
Electrical installation WARNING ▪ If the power supply has a missing or wrong N-phase, equipment might break down. ▪ Establish proper earthing. Do NOT earth the unit to a utility pipe, surge absorber, or telephone earth. Incomplete earthing may cause electrical shock. ▪... - Page 70 Electrical installation Use the following methods for installing wires: Wire type Installation method Single-core wire AA´ A´ Stranded conductor wire twisted to "solid-like" connection a Curled wire (single-core or twisted stranded conductor wire) b Screw c Flat washer Stranded conductor wire with round crimp-style terminal a Terminal...
-
Page 71: Specifications Of Standard Wiring Components
Electrical installation 18.1.3 Specifications of standard wiring components Power supply Voltage 220~240 V/220 V Frequency 50/60 Hz Phase Current FXHA32: 0.5 A FXHA50: 0.6 A FXHA63: 0.7 A FXHA100: 1.3 A Components Power supply cable MUST comply with national wiring regulation. 3-core cable Wire size based on the current, but not less than 1.5 mm Transmission wiring Only use harmonised wire providing double... - Page 72 Electrical installation 1 Remove the service cover. 2 Open the knockout hole and install the resin bushing (accessory). Refer to: "To mount the indoor unit" [ 55]. The location depends on the power supply wiring route. For transmission and user interface cable, choosing the same route as the refrigerant piping is recommended.
- Page 73 Electrical installation l Connection of power supply cable m Wiring fixture fixed with a screw (accessory) n Tie wrap (accessory) 7 Seal all gaps with sealing material (accessory) to prevent small animals from entering the system. 8 Reattach the service cover. Complete system example 1 user interface controls 1 indoor unit.
-
Page 74: Finishing The Indoor Unit Installation
Finishing the indoor unit installation 19 Finishing the indoor unit installation NOTICE Block any gaps around pipes and cables with sealing material (accessory) to avoid dust from entering the indoor unit. 19.1 To mount the suction grille and decoration side panel 1 Install securely in the reverse order. -
Page 75: Commissioning
20 Commissioning NOTICE General commissioning checklist. Next to the commissioning instructions in this chapter, a general commissioning checklist is also available on the Daikin Business Portal (authentication required). The general commissioning checklist is complementary to the instructions in this chapter and can be used as a guideline and reporting template during commissioning and hand-over to the user. -
Page 76: Checklist Before Commissioning
Commissioning NOTICE Cooling operation mode. Perform the test run in cooling operation mode so that stop valves failing to open can be detected. Even if the user interface was set to heating operation mode, the unit will run in cooling operation mode during 2‑3 minutes (although the user interface will display the heating icon), and then automatically switch to heating operation mode. -
Page 77: Configuration
Configuration 21 Configuration 21.1 Field setting Make the following field settings so that they correspond with the actual installation setup and with the needs of the user: ▪ Ceiling height ▪ Air volume when thermostat control is OFF ▪ Time to clean air filter ▪... - Page 78 Configuration If you want… Then — During thermostat 12 (22) OFF at cooling Setup volume operation Monitoring 1 Monitoring 2 During thermostat 12 (22) OFF at heating Setup volume operation Monitoring 1 Monitoring 2 Only use in combination with optional remote sensor or when setting M 10 (20), SW 2, — 03 is used.
- Page 79 Configuration Setting: Thermostat differential changeover (if remote sensor is used) If the system contains a remote sensor, set the increase/decrease increments. If you want to change increments to… Then — 1°C 12 (22) 0.5°C Setting: Automatic changeover differential Set the temperature difference between the cooling setpoint and the heating setpoint in automatic mode (availability depends on the system type).
- Page 80 Configuration FORCED Input A a Forced OFF b Input A Wiring requirements Wiring specification Only use harmonized wire providing double insulation and suitable for applicable voltage 2-core cable Wiring size Minimum 0.75 mm Wiring length Maximum 100 m External contact specification Contact that can make and break the min.
-
Page 81: Hand-Over To The User
Hand-over to the user 22 Hand-over to the user Once the test run is finished and the unit operates properly, make sure the following is clear for the user: ▪ Make sure that the user has the printed documentation and ask him/her to keep it for future reference. -
Page 82: Troubleshooting
Troubleshooting 23 Troubleshooting 23.1 Solving problems based on error codes If the unit runs into a problem, the user interface displays an error code. It is important to understand the problem and to take measures before resetting an error code. This should be done by a licensed installer or by your local dealer. This chapter gives you an overview of most possible error codes and their descriptions as they appear on the user interface. - Page 83 Troubleshooting Code Description Room temperature thermistor in remote controller abnormality FXHA-A Installer and user reference guide VRV system air conditioner 4P673749-1A – 2022.11...
-
Page 84: Disposal
Disposal 24 Disposal NOTICE Do NOT try to dismantle the system yourself: dismantling of the system, treatment of the refrigerant, oil and other parts MUST comply with applicable legislation. Units MUST be treated at a specialised treatment facility for reuse, recycling and recovery. FXHA-A Installer and user reference guide VRV system air conditioner... -
Page 85: Technical Data
Technical data 25 Technical data ▪ A subset of the latest technical data is available on the regional Daikin website (publicly accessible). ▪ The full set of latest technical data is available on the Daikin Business Portal (authentication required). 25.1 Wiring diagram 25.1.1 Unified wiring diagram legend... - Page 86 Technical data Symbol Meaning AC*, CN*, E*, HA*, HE*, HL*, HN*, HR*, Connection, connector MR*_A, MR*_B, S*, U, V, W, X*A, K*R_*, NE D*, V*D Diode Diode bridge DIP switch Heater FU*, F*U, (for characteristics, refer to Fuse PCB inside your unit) Connector (frame ground) Harness H*P, LED*, V*L...
- Page 87 Technical data Symbol Meaning Thermo switch Residual current device Resistor Thermistor Receiver Limit switch Float switch S*NG Refrigerant leak detector S*NPH Pressure sensor (high) S*NPL Pressure sensor (low) S*PH, HPS* Pressure switch (high) S*PL Pressure switch (low) Thermostat S*RH Humidity sensor S*W, SW* Operation switch SA*, F1S...
-
Page 88: Glossary
Optional equipment Equipment made or approved by Daikin that can be combined with the product according to the instructions in the accompanying documentation. Field supply Equipment NOT made by Daikin that can be combined with the product according to the instructions in the accompanying documentation. - Page 92 4P673749-1A 2022.11 Verantwortung für Energie und Umwelt...
