- Page 1 EDUS39-600A-F5 202103 Engineering Data Ceiling Suspended Type FXHQ-MVJU 60 Hz...
-
Page 3: Table Of Contents
FXHQ-MVJU EDUS39-600A-F5 Table of Contents 1. Features and Benefits ................2 2. Specifications .....................3 3. Dimensions ....................5 4. Piping Diagrams ..................8 5. Wiring Diagrams ..................9 6. Electric Characteristics ................11 7. Safety Device Setting ................12 8. Capacity Tables ..................13 8.1 Cooling Capacity at Te: 43°F (6°C) ..........13 8.2 Heating Capacity ................13 8.3 Correction Factor for Cooling Capacity at Te: 48°F (9°C) ....13... -
Page 4: Features And Benefits
FXHQ-MVJU EDUS39-600A-F5 1. Features and Benefits Slim, Efficient, Quiet, Easy to Maintain With its slim, elegant design, the FXHQ ceiling-suspended unit is a great fit for any light commercial space. Wide air openings provide a comfortable airflow, and an innovative stream fan ensures quiet operation, making it ideal for retail stores, restaurants, classrooms and conference rooms. „ Slim design of less than 8” in height makes it an ideal fits within any interior design „ Wide air discharge outlet distributes a comfortable airflow throughout the space with throw of up to 25 ft. „ Innovative stream fan technology allows for operating sound level as low as 38 dB(A) „ Simple cleaning thanks to the unit’s smooth flat louver design and its bristle-free frap that minimizes contamination „ Long-life filter included as standard „ Wide air discharge of 100° for optimal air spread „ Components are accessible from under the unit for ease of maintenance and service „ Models range from 12 MBH to 36 MBH „ Backed by 10 year parts limited warranty Non-dew Frap Sound absorption... -
Page 5: Specifications
FXHQ-MVJU EDUS39-600A-F5 2. Specifications Ceiling suspended type Model FXHQ12MVJU FXHQ24MVJU Power supply 1 phase, 60 Hz, 208/230 V 1 phase, 60 Hz, 208/230 V H1, H3 Cooling capacity Btu/h 12,000 24,000 H2, H3 Heating capacity Btu/h 13,500 27,000 Casing / Color White (10Y9/0.5) White (10Y9/0.5) Dimensions: (H × W × D) 7-11/16 ×... - Page 6 FXHQ-MVJU EDUS39-600A-F5 Ceiling suspended type Model FXHQ36MVJU Power supply 1 phase, 60 Hz, 208/230 V H1, H3 Cooling capacity Btu/h 36,000 H2, H3 Heating capacity Btu/h 40,000 Casing / Color White (10Y9/0.5) Dimensions: (H × W × D) 7-11/16 × 62-5/8 × 26-3/4 Rows × Stages × FPI Coil (cross fin 2 ×...
-
Page 7: Dimensions
FXHQ-MVJU EDUS39-600A-F5 3. Dimensions FXHQ12MVJU... - Page 8 FXHQ-MVJU EDUS39-600A-F5 FXHQ24MVJU...
- Page 9 FXHQ-MVJU EDUS39-600A-F5 FXHQ36MVJU...
-
Page 10: Piping Diagrams
FXHQ-MVJU EDUS39-600A-F5 4. Piping Diagrams FXHQ12-36MVJU 4D024460P Unit: in. Model Liquid FXHQ12MVJU f1/2 f1/4 FXHQ24-36MVJU f5/8 f3/8... -
Page 11: Wiring Diagrams
NOTES) : TERMINAL BLOCK : CONNECTOR : SHORT CIRCUIT CONNECTOR : FIELD WIRING 3. IN CASE USING CENTRAL REMOTE CONTROLLER, CONNECT IT TO THE UNIT IN ACCORDANCE WITH THE ATTACHED INSTRUCTION MANUAL. 4. X23A IS CONNECTED WHEN THE WIRELESS REMOTE CONTROLLER KIT IS BEING USED. 5. - Page 12 FXHQ-MVJU EDUS39-600A-F5 FXHQ12-36MVJU ELECTRICAL COMPONENTS AND WIRING CONNECTORS FOR INDOOR UNIT PRINTED CIRCUIT BOARD CAPACITOR (M1F) FUSE ( 5 A, 250 V) LIGHT EMITTING DIODE (SERVICE MONITOR-GREEN) MAGNETIC RELAY (M1S) MAGNETIC RELAY MOTOR (INDOOR FAN) MOTOR (SWING FLAP) THERMO SWITCH (M1F EMBEDDED) THERMISTOR (AIR) THERMISTOR (COIL LIQUID) THERMISTOR (COIL GAS) LIMIT SWITCH (SWING FLAP) TRANSFORMER (208-230 V / 25 V ) V1TR TRIAC TERMINAL BLOCK (POWER) TERMINAL BLOCK (CONTROL) ELECTRONIC EXPANSION VALVE RECEIVER / DISPLAY UNIT (ATTACHED TO WIRELESS REMOTE CONTROLLER) PRINTED CIRCUIT BOARD PRINTED CIRCUIT BOARD PUSH BUTTON (ON/OFF) LIGHT EMITTING DIODE (ON-RED) LIGHT EMITTING DIODE (TIMER-GREEN) LIGHT EMITTING DIODE (FILTER SIGN-RED) LIGHT EMITTING DIODE (DEFROST-ORANGE) SELECTOR SWITCH (MAIN/SUB) SELECTOR SWITCH (WIRELESS ADDRESS SET) CONNECTOR FOR OPTIONAL PARTS CONNECTOR (WIRING ADAPTOR FOR ELECTRICAL APPENDICES) X18A CONNECTOR (WIRELESS REMOTE CONTROLLER) X23A C: 3D048116C...
-
Page 13: Electric Characteristics
FXHQ-MVJU EDUS39-600A-F5 6. Electric Characteristics FXHQ12-36MVJU Power supply Input (W) Model SCCR Volts Voltage range Cooling Heating FXHQ12MVJU 0.062 SCCR kA rms, Max. 253 V FXHQ24MVJU 208/230 V 0.130 Symmetrical Min. 187 V @600 V MAX: 5 FXHQ36MVJU 0.130 Symbol: MCA: Minimum Circuit Ampacity (A) MOP: Maximum Overcurrent Protective Device (A) KW: Fan Motor Rated Output (kW) FLA: Full Load Ampacity (A) IFM: Indoor Fan Motor SCCR: S hort-Circuit Current Rating Note: 1. Voltage range... -
Page 14: Safety Device Setting
FXHQ-MVJU EDUS39-600A-F5 7. Safety Device Setting Model FXHQ12MVJU FXHQ24MVJU FXHQ36MVJU Printed circuit board fuse 250 V, 5 A 250 V, 5 A 250 V, 5 A Fan motor thermal fuse °F – – – OFF: 266±9 OFF: 266±9 OFF: 266±9 Fan motor thermal protector °F ON: 176±36 ON: 176±36 ON: 176±36 C: 3D049334A... -
Page 15: Capacity Tables
FXHQ-MVJU EDUS39-600A-F5 8. Capacity Tables Cooling Capacity at Te: 43°F (6°C) Indoor air temp. °FWB (°CWB) (Te: 43°F (6°C)) 61 (16.1) 64 (17.8) 67 (19.4) 70 (21.1) 72 (22.2) 75 (23.9) Model FXHQ12MVJU 10.7 12.0 12.7 12.9 13.1 FXHQ24MVJU 18.9 15.3 21.5 16.6 24.0 17.1 25.5 17.4 25.8 17.1 26.3 16.2 FXHQ36MVJU 28.4 21.8... -
Page 16: Air Velocity And Temperature Distributions (Reference Data)
FXHQ-MVJU EDUS39-600A-F5 9. Air Velocity and Temperature Distributions (Reference Data) Cooling Mode FXHQ12MVJU <Cooling mode> AIRFLOW DISTRIBUTIONS TEMPERATURE DISTRIBUTIONS C: 3D052938... - Page 17 FXHQ-MVJU EDUS39-600A-F5 FXHQ24MVJU <Cooling mode> AIRFLOW DISTRIBUTIONS TEMPERATURE DISTRIBUTIONS C: 3D052939...
- Page 18 FXHQ-MVJU EDUS39-600A-F5 FXHQ36MVJU <Cooling mode> AIRFLOW DISTRIBUTIONS TEMPERATURE DISTRIBUTIONS C: 3D052940...
-
Page 19: Heating Mode
FXHQ-MVJU EDUS39-600A-F5 Heating Mode FXHQ12MVJU <Heating mode> AIRFLOW DISTRIBUTIONS TEMPERATURE DISTRIBUTIONS C: 3D052938... - Page 20 FXHQ-MVJU EDUS39-600A-F5 FXHQ24MVJU <Heating mode> AIRFLOW DISTRIBUTIONS TEMPERATURE DISTRIBUTIONS C: 3D052939...
- Page 21 FXHQ-MVJU EDUS39-600A-F5 FXHQ36MVJU <Heating mode> AIRFLOW DISTRIBUTIONS TEMPERATURE DISTRIBUTIONS C: 3D052940...
-
Page 22: Sound Levels (Reference Data)
FXHQ-MVJU EDUS39-600A-F5 10. Sound Levels (Reference Data) 10.1 Overall n Ceiling suspended type Note: Operation noise differs with operation and ambient conditions. 208/230 V, 60 Hz Model FXHQ12MVJU FXHQ24MVJU FXHQ36MVJU... -
Page 23: Octave Band Level
FXHQ-MVJU EDUS39-600A-F5 10.2 Octave Band Level 208/230 V, 60 Hz FXHQ12MVJU FXHQ24MVJU C: 4D052512 C: 4D052513 FXHQ36MVJU C: 4D052514... -
Page 24: Accessories
FXHQ-MVJU EDUS39-600A-F5 11. Accessories 11.1 Optional Accessories (for Unit) Option FXHQ12MVJU FXHQ24MVJU FXHQ36MVJU Replacement long-life filter (resin net) KAFJ501D56 KAFJ501D112 KAFJ501D160 L-type piping kit (for upward direction) KHFP5M35 KHFP5M63 KHFP5M160 C: 3D049335C... - Page 28 Improper installation can result in water or refrigerant leakage, electrical shock, fire or explosion. Use only those parts and accessories supplied or specified by Daikin. Ask a qualified installer or contractor to install those parts and accessories. Use of unauthorised parts and accessories or improper installation of parts and accessories can result in water or refrigerant leakage, electrical shock, fire or explosion.
