DS31-EZ
Box contents
(1) Speaker assembly
(1) Cylindrical or Tapered sleeve
(1) Magnetic grille
(1) Mounting Assembly
(2) Mounting screws
(2) 2.25" sleeve screws
(2) 0.50" screws
(2) Wire nuts
Mounting screws (2)
Tapered Sleeve
Speaker
Warning
SoundTube speakers must be installed by a professional audio installer/contractor. For safety and for
optimum audio performance, installer must follow all directions issued by SoundTube Entertainment.
Install Instructions For:
DS31-EZ
Safety leash
Safety Clip
Grille
Dual-Gang Junction Box (not included)
Mounting plate
Adjustment loop
Cover plate
1.435.647.9555
© 2022 SoundTube Entertainment, Inc. All rights reserved. PN INS-DS31-EZ Rev 11.02.22
Do not spec or install speaker near support beam, ventilation duct or
other structure that may interfere with speaker function or dispersion.
Tap Settings
Tapered Sleeve
Cylindrical Sleeve
(two pieces)
|
800.647.TUBE
Warning
|
www.soundtube.com
