Altronix HubWayLDH8/16 Active UTP Transceiver Hub transmits UTP video and RS422/RS485 data over a single
CAT-5 or higher structured cable. Unit provides 8 or 16 camera channels in a space saving 1U EIA 19" rack mount
chassis which may be rack, wall or shelf mounted. Video transmission range is up to 3000 ft. max. per channel.
Units are compatible with fixed or PTZ cameras. An optional HubSat4D Passive UTP Transceiver Hub with Integral
Camera Power can be used as an accessory module to transmit video from up to 4 cameras over a single CAT-5
or higher structured cable back to the HubWayLDH8/LDH16. In addition, the HubSat4D provides power to these
cameras locally to eliminate the possibility of voltage drop associated with long cable runs.
HubWayLDH8
Input:
• 115VAC 60Hz, 1.5A or 230VAC 50/60Hz, 1A.
Video:
• Eight (8) channels of video over twisted pair up to
a distance of 3,000 ft. per channel.
• Eight (8) 75 ohm video outputs.
Agency Listings:
• UL Listed for Commercial CCTV Equipment
(UL 2044).
CUL Listed - CSA Standard C22.2 No.1-04,
Audio, Video and Similar Equipment.
• CE European Conformity.
Data:
• RS422/RS485 data inputs.
Visual Indicators:
• AC input power indicator.
• Video signal LED indicators.
WARNING: To reduce the risk of fire or electric shock do not expose the unit to rain or moisture.
This installation should be made by qualified service personnel and should conform to all local codes.
- 2 -
Overview:
HubWayLDH Specifications:

Common Specifications:

HubWayLDH16
Input:
• 115VAC 60Hz, 3A or 230VAC 50/60Hz, 1.5A.
Video:
• Sixteen (16) channels of video over twisted pair up
to a distance of 3,000 ft. per channel.
• Sixteen (16) 75 ohm video outputs.
Features:
• Picture and Gain control.
• Illuminated master power disconnect circuit breaker
with manual reset.
• IEC 320 - 3-wire grounded line cord (detachable).
• Unit can be rack, wall or shelf mounted.
• 1U rack mount chassis for use in standard
EIA 19" rack.
Accessories:
• Optional HubSat4D allows transmission of up to
four (4) video signals over a single CAT-5 or
higher structured cable.
