Technical Specifications
Product Codes
Power Requirements
- Holding Position
- Holding Position
Transformer Sizing Requirements
- Minimum per Actuator 25 VA
Auxiliary Switch Rating
Spring Return
Running and Spring Return Torque
Rotation Range
Rotation Time
- Power On (Running) 24 to 57 Seconds for 0 to 20 Nm at All Operating Conditions
- Power Off (Spring Returning) 35 Seconds Nominal at Full Rated Load
Cycles
Audible Noise Rating
- Power On (Running) <66 dBA at 1 m
- Power On (Holding) <18 dBA at 1 m
- Power Off (Spring Returning) <66 dBA at 1 m
Electrical Connections
(Actuator and Auxiliary Switches)
Conduit Connections
Mechanical Connections
- Standard Shaft Clamp Included with Actuator 12 to 19 mm Diameter Round Shafts, or 10, 12, and 14 mm Square Shafts
- Optional M9220-600 Jackshaft Coupler Kit 19 to 27 mm Diameter Round Shafts, or 16, 18, and 19 mm Square Shafts
Aluminum Enclosure
Ambient Conditions
Shipping Weight
Dimensions
Compliance
- Australia and New Zealand C-Tick Mark, Australia / NZ Emissions Compliant
IS_DA-020S230DX / DA-020S230D2 / DA-020S024DX / DA-020S024D2_14-88360-03346_Rev. -_09 2017
DA-020S024DX / DA-020S024D2
ON/OFF
AC 24 V (AC 19.2 to 28.8 V) at 50/60 Hz
Class 2 (North America) or SELV (Europe)
- Running
DC 24 V (DC 21.6 to 26.4 V),
Class 2 (North America) or SELV (Europe)
- Running
Two Single-Pole, Double-Throw (SPDT), Double-Insulated Switches with Gold Flash Contacts:
AC 24 V, 50 VA Pilot Duty;
AC 120 V, 5.8 A Resistive, 1/4 hp, 275 VA Pilot Duty;
AC 240 V, 5.0 A Resistive, 1/4 hp, 275 VA Pilot Duty
Direction is Selectable with Mounting Position of Actuator:
Side A, Actuator Face Away from Damper for CCW Spring Return
Side B, Actuator Face Away from Damper for CW Spring Return
20 Nm for a Single Actuator;
40 Nm for Two Like Models Mounted in Tandem
Optional M9220-603 Adjustable Stop Kit
Adjustable from 30 to 90° CW or CCW, Mechanically Limited to 90°
11 to 15 Seconds for 0 to 20 Nm at Room Temperature
35 Seconds maximum for 0 to 20 Nm at -30 °C
130 Seconds maximum for 0 to 20 Nm at -40 °C
60,000 Full Stroke Cycles; 1,500,000 repositions
1.2 m Halogen-Free Cable with 18 AWG (0.75 mm
Integral Connectors for 10 mm Flexible Metal Conduit
NEMA 2 (IP54) for All Mounting Orientations
- Operating -40 to 55 °C; 90% RH Maximum, Noncondensing
- Storage -65 to 85 °C; 95% RH Maximum, Noncondensing
See Figure 1
- United States UL Listed, CCN XAPX, File E27734; to UL 60730-1A: 2003-08, Ed. 3.1, Automatic Electrical Controls for Household and
Similar Use; and UL 60730-2-14: 2002-02, Ed. 1, Part 2, Particular Requirements for Electric Actuators.
- Canada UL Listed, CCN XAPX7, File E27734; to UL 60730-1:02-CAN/CSA: July 2002, 3rd Ed., Automatic Electrical Controls for
Household and Similar Use; and CSA C22.2 No. 24-93 Temperature Indicating and Regulating Equipment.
- Europe Distech Controls SAS, declares that these products are in compliance with the essential requirements and other relevant
provisions of the EMC Directive and Low Voltage Directive.
26 VA
9.3 VA
17.6 W
2.8 W
) Wire Leads
2
2.9 kg
DA-020S230DX / DA-020S230D2
AC 230 V (AC 198 to 264 V) at 50/60 Hz
0.15 A
0.09 A
---
---
---
3.5 Kg
