H RESOLUTION
INPUT VGA, RGB/HV only
V RESOLUTION
INPUT VGA, RGB/HV only
INPUT RESOLUTION
INPUT VGA, RGB/HV only
ADJUST RESET

AUDIO

BALANCE
TREBLE
BASS
AUDIO RESET

SCHEDULE

OFF TIMER
SCHEDULE
DATE AND TIME
SCHEDULE RESET

PIP

PIP MODE
OFF
PIP
POP
SBS ASPECT
SBS FULL
PIP SIZE
PIP AUDIO
PIP H-POSITION
PIP V-POSITION
TEXT TICKER
MODE
POSITION-H
POSITION-V
SIZE
BLEND
DETECT
FADE IN
SUB INPUT
PIP RESET

OSD

LANGUAGE
OSD TURN OFF
Adjusts the horizontal size of the image.
Press + button to expand, and press - button to narrow the width of the image on the screen.
Adjusts the vertical size of the image.
Press + button to expand, and press - button to narrow the width of the image on the screen.
Selects to decision of input signal timings 1024x768, 1280x768, 1360x768 and 1366x768 if there is a detection
problem. If no problem is detected, the only available option will be "AUTO".
Resets the all settings within the ADJUST menu back to factory setting.
Adjust the balance of L/R volume.
To accentuate or reduce the high frequency sound. Press + to increase, press - to decrease.
To accentuate or reduce the low frequency sound. Press + to increase, press - to decrease.
Resets the all settings within the AUDIO menu back to factory setting.
Sets the monitor to power off after a length of time.
A time between 1 to 24 hours is available.
Creates a working schedule for the monitor to use.
(See "NOTE 1" on page 23 for further information).
Sets the date, time, and daylight saving region.
Setting item: YEAR/MONTH/DAY/HOUR/MINUTE/DAYLIGHT SAVING TIME
Date & time must be set in order for the "SCHEDULE" function to operate.
Resets the all settings within the SCHEDULE menu back to factory setting except DATE AND TIME setting.
Selects Picture-in-Picture mode. See page 10.
Normal mode.
Picture in Picture mode.
Picture out picture mode.
Side by side (split screen) mode, with keep aspect.
Side by side (split screen) mode, with full screen.
Selects the size of sub-picture used in "Picture-in-Picture" (PIP) mode.
"LARGE", "MIDDLE" and "SMALL" are available.
Selects the sound source in PIP mode.
Determines where the PIP appears on the screen.
Determines where the PIP appears on the screen.
Enables Text Ticker and allows you to set Horizontal or Vertical direction.
Selects the horizontal location of the Text Ticker on the screen.
Selects the vertical location of the Text Ticker on the screen.
Determines the size of the Text Ticker in relationship to the overall screen size.
Sets the transparency of the Text Ticker (10: transparent, 100: opaque).
Enables auto-detection of the Text Ticker.
Enables fade-in of the text ticker when DETECT is AUTO.
Selects sub picture input signal.
Resets the all settings within the PIP menu back to factory setting.
Selects the language used by the OSD from seven languages.
ENGLISH/DEUTSCH/FRANÇAIS/ESPAÑOL/ITALIANO/SVENSKA/
Turns off the OSD after a period of inactivity. The preset choices are 5 - 120 seconds.
English-20
