Specifications - V321

Product Specifications
LCD Module
Frequency
Pixel Clock
Viewable Size
Input Signal
DVI
DVI-D 24pin
VGA
15pin Mini D-sub
2
RGB/HV*
BNC (R,G,B,H,V)
HDMI
HDMI Connector
DVD/HD*
2
BNC (Y, Cb/Pb, Cr/Pr)
S-VIDEO
Mini DIN 4 pin
VIDEO1
BNC
VIDEO2*
2
BNC
Output Signal
RGB
15pin Mini D-sub
VIDEO
BNC
AUDIO
AUDIO
RCA (L/R) X2
Input
STEREO Mini Jack
AUDIO
RCA (L/R)
Output
Speaker Output
Control
Power Supply
Operational Environment
Storage Environment
Dimension
Weight
VESA compatible arm mounting interface
Power Management
Plug & Play
Accessories
NOTE: Technical specifications are subject to change without notice.
32"/80.0 cm diagonal
Pixel Pitch:
0.511 mm
Resolution:
1366 x 768 dots
Color:
Over 16 million colors (depending on video card used)
Brightness:
450 cd/m
Contrast Ratio:
3000:1
Viewing Angle:
89° (typ) @ CR>10
Design View Distance:
875 mm
Horizontal:
15.625/15.734 kHz, 31.5 kHz - 91.1 kHz
Vertical:
50.0 - 85.0 Hz
25.0 MHz - 165.0 MHz
697.7 x 392.3 mm
Digital RGB
DVI (HDCP)
VGA60, SVGA60, XGA60, WXGA60, SXGA60*
Analog RGB
0.7 Vp-p/75 ohm
VGA60, SVGA60, XGA60, WXGA60, SXGA60*
Sync
Separate: TTL level (Pos./Neg.)
Analog RGB
0.7 Vp-p/75 ohm
VGA60, SVGA60, XGA60, WXGA60, SXGA60*
Sync
Separate: TTL level (Pos./Neg.)
Digital RGB
HDMI
1080p, 1080i, 720p@50Hz/60Hz, 576p@50Hz, 480p@60Hz
Component
Y: 1.0 Vp-p/75ohm, Cb/Cr (Pb/Pr): 0.7 Vp-p/75 ohm
HDTV/DVD: 1080i@60Hz*
S-VIDEO
Y: 1.0 Vp-p/75 ohm C: 0.286 Vp-p/75 ohm (NTSC), 0.3 Vp-p/75 ohm (PAL/SECAM)
NTSC/PAL/SECAM/4.43NTSC/PAL60
Composite
1.0 Vp-p/75 ohm
NTSC/PAL/SECAM/4.43NTSC/PAL60
Analog RGB
0.7 Vp-p with 75 ohm terminated
Separate HV sync: TTL level (Pos. / Neg.)
Composite
1.0 Vp-p with 75 ohm terminated
Analog Audio
Stereo L/R 0.5 Vrms
Analog Audio
Stereo L/R 0.5 Vrms
External Speaker Jack 7 W + 7 W (8 ohm)
RS-232C In:
9 Pin D-sub
RS-232C Out:
9 Pin D-sub (with daisy chain)
LAN:
RJ-45 10/100 BASE-T
1.4 - 0.6 A @ 100-240VAC, 50/60Hz
Temperature:
5 - 40°C (landscape), 5 - 35°C (portrait)
Humidity:
20 - 80% (without condensation)
Altitude:
0 - 3000 m
Temperature:
-20 - 60°C
Humidity:
10 - 90% (without condensation)/ 90% - 3.5% x (Temp - 40°C) regarding over 40°C
Net:
789 (W) x 476.3 (H) x 133 (D) mm
14.3 kg/31.5 lbs
200 mm x 200 mm (4 Holes)
VESA DPM
VESA DDC2B, DDC/CI
Setup manual, Power Cord, Video Signal Cable, Remote Control, AAA Battery x 2, Clamp x 2,
Screw for Main switch cover x 2, Screw for Clamp x 2, CD-ROM, Main switch cover
2
(Max.)
1
, 1080p@60Hz*
1
, 720p@50Hz/60Hz, 576p@50Hz, 480p@60Hz, 576i@50Hz, 480i@60Hz
English-30
1
, UXGA60*
1
, 1920 x 1080*
1
(60Hz)
1
, UXGA60*
1
, 1920 x 1080*
1
(60Hz)
1
1
1
, UXGA60*
, 1920 x 1080*
(60Hz)
*1: Compressed image
*2: Shared use
