Connections

NOTE: Do not connect/disconnect cables when turning on the monitor or other external equipment as this may result in a
loss of the monitor image.
NOTE: Use an audio cable without a built-in resistor. Using an audio cable with a built-in resistor turns down the sound.
Before making connections:
*
First, turn off the power of all attached equipment and make connections.
*
Refer to the user manual included with each separate piece of equipment.

Wiring Diagram

Stereo Amplifier
Computer (Analog)
*: Multiple monitors that are daisy-chained have a limit to the connectable monitors.
Connected
Connecting
equipment
terminal
DVI (DVI-D)
HDMI
AV
DVD/HD (5BNC)
S-VIDEO
VIDEO1 (BNC)
VIDEO2 (5BNC)
DVI (DVI-D)
PC
VGA
RGB/HV (5BNC)
*1: depend on signal type.
AUDIO IN 1, 2 and 3 can be used for audio input. To select audio source [IN1], [IN2] or [IN3] by pressing the AUDIO
INPUT button (remote control).
VCR Player
Computer (Digital)
Setting in Terminal Mode
DVI MODE: DVI-HD
1
RAW/EXPAND*
BNC MODE: COMPONENT
-
-
BNC MODE: VIDEO
DVI MODE: DVI-PC
-
BNC MODE: RGB
English-14
DVD Player
DVD player
with HDMI out
Input signal
Connecting
name
Audio terminal
DVI
AUDIO IN1, IN2, IN3
HDMI
HDMI
DVD/HD
AUDIO IN1, IN2, IN3
S-VIDEO
AUDIO IN1, IN2, IN3
VIDEO1
AUDIO IN1, IN2, IN3
VIDEO2
AUDIO IN1, IN2, IN3
DVI
AUDIO IN1, IN2, IN3
VGA
AUDIO IN1, IN2, IN3
RGB/HV
AUDIO IN1, IN2, IN3
Second monitor*
