DESK
( picture 2)
Thank you for choosing our product
Email all question to: help@vivo-us.com
This product contains small items that could be a choking hazard if swallowed. Keep
these items away from young children!
1.Make sure these instructions are read and completely understood before attempting
installation. If you are unsure of any part of this installation, contact a professional
installer for assistance.
2.The wall or mounting surface must be capable of supporting the combined weight of
the mount and the display; otherwise the structure must be reinforced.
3.Safety gear and proper tools must be used. A minimum of two people are required
for this installation. Failure to use safety gear can result in property damage, serious
injury or death.
-4-
A,B
CABLE
( picture 3)
Warning
INSTALLATION GUIDE
Item No.:STAND-V001S
Screen Size Range: 10"~27"
Max load capacity of each mounting bracket:
8Kg/17.6lbs
Integrated Cable management
CAUTION
Please read this guide before installation.
Ensure the correct installation. Keep away from high frequency or power equipment to
avoid disturbance.Choose desk to put this product.
We can not be responsible for any damage caused by wrong installation.
