Adapter Bracke Br Bracke a cket Assembly
Instruction Manual
Model: STAND- STAND-VAD1B VAD-VAD1B1B
Email: help@vivo-us.com
Live chat: www.vivo-us.com
Call: 1-800-371-5654
-
Scan the QR code with your mobile device or follow the link
to helpful videos and specifications related to this product.
https: STAND- / /vivo us.com/pr Bracke o ducts/stand vad1b
-
Tools Requir Bracke e d: STAND-
phillips screwdriver
Package Contents
A (x4)
Bracket Arm Arm
B (x4)
" L" Suppor Support Arm
D-VAD1B (x8)
Nut Arm
F (x4)
M6x40
H (x4)
M6x80
-
C (x4)
Plast Arm i c Cover
E (x8)
Carriage Bolt Arm
G (x4)
M6x60
I (x1)
Wrench
1
