GREAT PYRENEES
Installation Instructions
The Great Pyrenees series antennas are the first to market with
8X8 MIMO LTE in a single, compact housing. This high-
performance, IP67-rated, 5G antenna with double 4X4 MIMO LTE,
2X2 MIMO Wi-Fi, Bluetooth, and GPS is perfect for mobile and
fixed wireless applications.
This rugged, omni-directional antenna supports two separate
LTE modems ideal for first responders and transportation
network solutions. The Great Pyrenees works on all common North American LTE bands, including band 17,
and supports PLTE and LAA.
Optional Accessories (sold separately)
-
Magnetic Mount Boot (PTA0197)
-
Pole Mounting Kit (PTA0149H): includes mounting bracket, clamp saddles (2 pcs), V-bolts (2 pcs), flat
washers (4 pcs), lock washers (4 pcs), and nuts (4 pcs)
-
Ground Plane with Adhesive Back (PTA0587)
-
Star Washer (PTA0257)
Required Tools
-
2.25" Wrench (Roof & Pole Mounting)
-
Drill (Roof Mounting)
-
0.1" or Similar Diameter Drill Bit (Roof Mounting)
Mounting Options
Select one of the mounting options below:
- Roof Mount (included)
Great Pyrenees antennas can be mounted on an automobile roof or any flat surface using the
hardware provided with it.
- Magnetic Mount (sold separately)
For temporary use, Great Pyrenees antennas can be mounted on a ferrous metal surface using a
magnetic boot.
-
Pole Mount (sold separately)
Great Pyrenees antennas can be affixed to a 1" to 2.25" diameter pole with a pole mounting kit.
Great Pyrenees Installation Instructions
-
1.5" Sheet Metal Hole Saw (Roof Mounting)
-
7/16" Wrench (Pole Mounting)
-
5/16" or 8mm 5 in.-lb. Torque Wrench
Page 1 of 8
Advertisement
Table of Contents
Related Manuals for Parsec Technologies GREAT PYRENEES Series
Summary of Contents for Parsec Technologies GREAT PYRENEES Series
- Page 1 GREAT PYRENEES Installation Instructions The Great Pyrenees series antennas are the first to market with 8X8 MIMO LTE in a single, compact housing. This high- performance, IP67-rated, 5G antenna with double 4X4 MIMO LTE, 2X2 MIMO Wi-Fi, Bluetooth, and GPS is perfect for mobile and fixed wireless applications.
- Page 2 Roof Mounting Instructions Preparing the Hole Step 1. Select an easily accessible mounting location on vehicle roof with no obstructions within a 24” radius. The antenna should be as far away as possible (at least 18”) from other roof-mounted devices such as light bars and other antennas to avoid de-tuning or interference issues.
-
Page 3: Mounting The Antenna
Mounting the Antenna Step 1. Clean any debris and dust off of the vehicle surface at the mounting location. Step 2. Feed the coaxial cables from the antenna through the hole from the outside. Step 3. Remove the backing from the adhesive pad on the underside of the antenna and place the antenna on the mounting surface. - Page 4 Magnetic Mount Instructions Step 1. Select a mounting location. The magnetic mount can be placed on ferromagnetic surfaces, such as iron, steel, and nickel. The antenna should be as far away as possible (at least 18”) from other roof-mounted devices such as light bars and other antennas to avoid de-tuning or interference issues. Step 2.
-
Page 5: Pole Mounting Instructions
Pole Mounting Instructions Installing the Pole Mount Bracket Step 1. Select a mounting location on a pole with a diameter between 1” and 2.25”. Ensure that the pole is vertical, stable, and rigid. Step 2. Install the pole mount bracket onto the pole with the provided hardware. Around the pole, insert the V-bolt through the clamp saddle then through the pole mount bracket. - Page 6 Mounting the Antenna Step 1. Feed the coaxial cables from the antenna through the hole in the bracket. Step 2. Remove the backing from the adhesive pad on the underside of the antenna and place the antenna on the bracket. Apply downward pressure on the antenna to ensure strong adhesion. Step 3.
-
Page 7: Cable Connection Instructions
Cable Connection Instructions Step 1. Use canned air and/or isopropyl alcohol to clean all the connectors to ensure that there is no dust in the terminals. Step 2. Connect the antenna cables to the router. Use the table below for reference; different routers may have different terminal names. - Page 8 This document gives the detailed instructions to install an antenna to the best of our knowledge. This document is for general information only. It cannot be used as a warranty. Parsec Technologies Inc. will not accept any liability for any damage caused by an antenna due to unknown variables.
- Page 9 Great Pyrenees Installation Instructions Rev: 10/7/2022 Completion Date: Greyson Long Author: Approval Date: Engineering Manager: Rauhon Shaik...
