BEAGLE
Installation Instructions
The Beagle is a low-profile, five-in-one MIMO LTE, MIMO WIFI, and GNSS antenna built into an IP67-rated*
enclosure. This rugged, low-profile, omni-directional antenna works on most of the common North
American LTE bands with high efficiency. The Beagle is optimized for LTE isolation.
Table of Contents
Antenna Versions ........................................................................................................................................................................................ 2
Required Tools & Accessories ................................................................................................................................................................ 2
Battery and Router Installation ............................................................................................................................................................. 3
Connection ..................................................................................................................................................................................................... 5
Final Assembly ............................................................................................................................................................................................ 10
Operational Setup ..................................................................................................................................................................................... 13
Battery Operation and Safety Guidelines....................................................................................................................................... 16
* Conditions apply
Advertisement
Related Manuals for Parsec Technologies Beagle G
Summary of Contents for Parsec Technologies Beagle G
-
Page 1: Table Of Contents
BEAGLE Installation Instructions The Beagle is a low-profile, five-in-one MIMO LTE, MIMO WIFI, and GNSS antenna built into an IP67-rated* enclosure. This rugged, low-profile, omni-directional antenna works on most of the common North American LTE bands with high efficiency. The Beagle is optimized for LTE isolation. Table of Contents Antenna Versions ...................................... -
Page 2: Antenna Versions
Antenna Versions The Beagle case antenna comes in two versions – G and L – with different features, listed below. Beagle G Beagle L • 2x RJ-45 Ports • AC Power Port • USB-A Port • 2x RJ-45 Ports • Battery Operated (battery not included) •... -
Page 3: Battery And Router Installation
Battery Tray Figure 1: Place the ChargeTech battery pack into the battery tray. (Beagle G) Figure 2: Fasten the battery tray with battery pack to the cover plate using PTA0368-B screws. (Beagle G) Beagle Installation Instructions Page 3 of 17... - Page 4 D. Guide the cable bundles back through the holes in the cover plate. Figure 3: Fasten the router to the cover plate using PTA0368-B screws. (Beagle L) Figure 4: Fasten the router to the cover plate using PTA0368-B screws. (Beagle G) Beagle Installation Instructions...
-
Page 5: Connection
Connection Figure 5: Connection Diagram for Beagle G Beagle Installation Instructions Page 5 of 17... - Page 6 Figure 6: Connection Diagram for Beagle L Beagle Installation Instructions Page 6 of 17...
- Page 7 Step 1: Connect the antenna cables to the router. A. Use canned air or isopropyl alcohol to clean all the connectors to ensure that there is no dust in the terminals. B. Connect the antenna cables to the designated terminals on the router, as shown in the tables and images below.
- Page 8 B. For Beagle L, plug the NEMA male to female adapter into the AC power port on the case. C. For Beagle G, plug the NEMA male to female adapter into AC outlet on the battery pack, shown in Figure 9.
- Page 9 B. Plug the provided USB-A cord into the USB-A port on the case and the USB-A port on the battery pack, shown in Figure 9. Step 6: Connect the battery pack to the DC charging port on the case (Beagle G only). A. This step only applies to the Beagle G.
-
Page 10: Final Assembly
B. Use cable ties or other wire management to neatly bundle the cables. Pack the cables neatly inside the bottom half of the case. Ensure that the antenna cables are not excessively bent (1/2” minimum bend radius). Figure 10: Fully Connected 5in1 Beagle G with Cradlepoint IBR900 Router Beagle Installation Instructions Page 10 of 17... - Page 11 Figure 11: Fully Connected 5in1 Beagle L with Cradlepoint IBR900 Router Beagle Installation Instructions Page 11 of 17...
- Page 12 Step 2: Fasten the cover plate to the case. A. Place the cover plate onto the bottom half of the case. Ensure that no cables are pinched between the cover plate and the case. B. Fasten the cover plate to the case using the eighteen PTA0071B black oval head screws provided in the kit, as shown in Figure 12.
-
Page 13: Operational Setup
Operational Setup Step 1: Open the fan and vent caps (Beagle G only). A. This step only applies to the Beagle G. B. Before turning the antenna ON, always open the fan and vent caps. The type of cap may vary. - Page 14 Step 3: Connect the antenna to a computer. A. Use an ethernet cable to connect a computer to the RJ-45 port on the case that is connected to the LAN port on the router. Step 4: Login to Cradlepoint NetCloud. A.
- Page 15 Step 5: Select the antenna in the device list on Cradlepoint NetCloud. A. On the left side of the page, select STATUS. From the dropdown menu, select INTERNET and then CONNECTIONS. B. In the Device List table, select the option with a cellular SIM, as shown in Figure 16. Figure 16: Select the device with a cellular SIM in Cradlepoint NetCloud.
-
Page 16: Battery Operation And Safety Guidelines
Battery Operation and Safety Guidelines A. To manually power ON/OFF, press and hold the power button (located on the top of the unit) for 3 seconds. All LED lights/display should turn ON/OFF. B. Holding the power button for longer than 3 seconds will cause the battery pack to enter programming mode. - Page 17 This document gives the detailed instructions to install an antenna to the best of our knowledge. This document is for general information only. It cannot be used as a warranty. Parsec Technologies Inc. will not accept any liability for any damage caused by an antenna due to unknown variables.
