- Page 1 TR100 User Manual...
- Page 2 Cattron Holdings, Inc., or any of its affiliates or agents shall not be liable for incidental or consequential damages of any kind. All Cattron products are sold pursuant to the Terms and Conditions of Sale, a copy of which will be furnished upon request. When used as a tradename herein, Cattron means Cattron Holdings, Inc.
-
Page 3: Table Of Contents
DynaGen TR100 - EN User Manual Contents Introduction ................................. 4 Limitations ............................... 4 Wiring and Setup ..............................5 Wiring ..............................5 TR100 Setup ............................5 Local TG350/TG410 Setup ........................5 Typical Wiring Diagram ........................... 5 Using the Remote Panel ............................. 7 Using the Menu System .......................... -
Page 4: Introduction
DynaGen TR100 - EN User Manual Introduction The TR100 is a J1939 remote panel for use with the TG350 and TG410 controllers. In a J1939 network, there can be one local engine controller (TG350 or TG410) paired with an unlimited number of remotes; it is recommended that this number be limited to five remotes. -
Page 5: Wiring And Setup
2. The remote panel must be provided with power and ground connections. TR100 Setup 1. Download the TR100 firmware from www.cattron.com/support/user-manuals/dynagen-user-manuals/ unzip it to the desktop. 2. Using RapidCore, program this firmware into a TG350 or TG410 to convert it into a TR100. - Page 6 DynaGen TR100 - EN User Manual 9M02-9350-A001-EN Revision A...
-
Page 7: Using The Remote Panel
DynaGen TR100 - EN User Manual Using the Remote Panel This section discusses how to use the remote panel. Using the Menu System Task Description Entering Menu When in the OFF Mode, press the Enter button to bring up the menu. Navigating Menu Once in the menu, use the up and down arrows to navigate. -
Page 8: Power Up
DynaGen TR100 - EN User Manual Item Name Description Generator LED Green = Engine running with no issues Amber = Engine running with warnings Red = Engine shut down on failure Power Up Whenever the remote panel is powered up, it will attempt to register with the local controller. This happens on every power up. -
Page 9: Failure Shutdown
DynaGen TR100 - EN User Manual Note that the remote is set up to work with certain systems only. It may not work with every TG350 or TG410 system. Check with your OEM for assistance. If communication with the controller is lost, the remote will display the following screen. Failure Shutdown If the local controller has shut down due to a failure, the following screen will be displayed on the remote panel. -
Page 10: Front Panel Menu
DynaGen TR100 - EN User Manual Front Panel Menu There are several settings the operator can change in the remote. The menu can only be accessed when the local controller is in the OFF or AUTO Modes. Pressing the Enter button allows the menu to be accessed. The following screen shows the main menu of the menu system. -
Page 11: Device Info
DynaGen TR100 - EN User Manual Name Range Description Page Scroll 1 to 10 s Adjusts the amount of time that each parameter screen is displayed in RUN Mode. (Default: 5 s) Message Pop-up 1 to 10 s Adjusts the amount of time that a message (event or warning) is displayed on the second line of the display in RUN Mode. -
Page 12: Starting And Stopping
DynaGen TR100 - EN User Manual 2) Numeric Adjustment An example of this type of setting is the LCD Contrast parameter in the Operator Setup > Display menu. Press up and down to change the setting. Press Enter to select the change. A checkmark will be displayed. Pressing Enter with the checkmark displayed will store the value and exit the menu. -
Page 13: Parameter Display
DynaGen TR100 - EN User Manual Starting with the remote panel can only be accomplished when the local controller is in the AUTO Mode; you must go to the local controller and put it in AUTO if the local controller is in the OFF Mode. When in AUTO Mode, the remote will display "System Ready, Waiting to Start". -
Page 14: Technical Support
DynaGen TR100 - EN User Manual Technical Support For remote and communication control systems support, parts and repair, or technical support, visit us online at: www.cattron.com/contact. 9M02-9350-A001-EN Revision A... - Page 15 Cattron Wireless Automation and Control Solutions Support For remote and communication control systems support, parts and repair, or technical support, visit us online at: www.cattron.com/contact Cattron North America Inc., 655 N River Rd NW, Suite A, Warren, OH 44483 9M02-9350-A001-EN Revision A...
