RAISING THE CURVED GLASS / OPENING REAR DOOR / REMOVING REAR DOORS

Raise the Curved Glass
• To raise the curved glass, secure lift handle
extrusion on the bottom edge of the door and
lift up.
• Caution: Gently return curved glass to original
position.
• See illustration below.
Opening Rear Door / Removing Rear Doors
• 26" Models have swinging clear glass door
View of Curved
Glass Being
Raised
that opens with either left hand (standard) or right
hand hinge (optional).
• All other models have removable rear doors
(see illustration below).
• Move rear doors toward the center of case.
• Individually lift each door up toward the top of case
and pivot bottom of the door out.
• Caution: Gently set doors down to avoid marring,
scraping, scratching or breakage.
11
View of Rear
Doors being
lifted up,
pivoted out
and away
from case.
Main Power Switch
(Self-Contained
Only)
