PREVENTIVE MAINTENANCE (TO BE PERFORMED BY TRAINED SERVICE PROVIDER)

WARNING! TURN OFF CASE BEFORE PERFORMING PREVENTIVE MAINTENANCE!
PREVENTIVE
MAINTENANCE
Case Exterior
Case Interior
FREQUENCY
Monthly Condensing Coil:
• Remove Rear Grille (by removing 4 screws).
• Use air pressure or industrial strength vacuum; clean dust
and dirt that may collect on the Condenser Coil. See
illustration below.
• Caution! Coil fins are sharp. Handle with care!
• Replace Rear Grille to case (4 screws).
Quarterly Evaporator Pan: Caution! Disconnect from receptacle box.
• Remove mounting screws from base.
• Use de-scaling solution (such as CLR® that will prevent
corrosion, lime and rust) to clean pan.
• Rinse thoroughly; do not submerse in water.
• Reattach pan to case with same mounting screws.
• Reconnect power cord to receptacle box.
Quarterly Compressor Area: Caution! Be certain to disconnect power
from case before cleaning Compressor Area!
• Slide/Roll compressor package out from under case.
• Use moist cloth to wipe off dust & debris that collects on
various parts.
• Slide/Roll compressor package back under case.
Quarterly Under Case Cleaning: Once refrigeration package is clear of
unit, vacuum under case to remove all dust and dirt that may
collect under case.
Quarterly Tub, Coil, Drain, Fan Blades, Motors, Brackets:
Disconnect power from the case before cleaning the tub, coil,
fan, motor and drain area!
• Remove Decking, Sub-Deck and Fan Shroud.
• Use vacuum to clean Evaporator Coils.
• Clean Tub, Coil and Drain with warm water, clean cloth,
brush and mild soap solution.
• Remove any debris that may clog drain.
• Clean Fan Blades, Motors and Brackets by wiping down
with moist cloth.
INSTRUCTIONS
