RAISING THE CURVED GLASS / OPENING REAR DOOR / REMOVING REAR DOORS

Raise the Curved Glass
•
To raise the curved glass, secure lift handle
extrusion on the bottom edge of the door and
lift up.
•
Caution: Gently return curved glass to original
position.
•
See illustration below.
Opening Rear Door / Removing Rear Doors
•
26" Models have swinging clear glass door
View of Curved
Glass being
raised
that opens with either left hand (standard) or
right hand hinge (optional).
•
All other models have removable rear doors (see
illustration below).
•
Move rear doors toward the center of case.
•
Individually lift each door up toward the top of
case and pivot bottom of the door out.
•
Caution: Gently set doors down to avoid
marring, scraping, scratching or breakage.
11
View of Rear
Doors being
lifted up,
pivoted out
and away
from case.
Main Power
Switch (Self-
Contained
Only)
