ASSEMBLY INSTRUCTIONS
Quadro Loop
Desk
Sizes: 1200, 1400, 1600, 1800 mm
STEP 06
Place desktop ontop of frame - with cutout at the back of the desk.
Nut inserts in top will align with plastic joiner brackets using M6x30MM
(I) sockets attached top to frame.
All manuals and user guides at all-guides.com
www.jasonl.com.au
Need help!
Call us on
1300 527 665
I
nut insert
TABLE TOP
BOTTOM VIEW
nut insert
Page 6 of 6
