ASSEMBLY INSTRUCTIONS
Quadro Loop
Desk
Sizes: 1200, 1400, 1600, 1800 mm
STEP 04
Attach beam (D) to legs (B) using nut insert in legs.
See point attached
All manuals and user guides at all-guides.com
TOP VIEW
www.jasonl.com.au
Need help!
Call us on
1300 527 665
STEP 05
F
Frame looks like this. Using Allen Key, attach beam (D) with Socket (F)
F
Page 5 of 6
