ASSEMBLY INSTRUCTIONS
Quadro Loop
Desk
Sizes: 1200, 1400, 1600, 1800 mm
COMPONENTS
A
Table top x1
B
Legs Quadro x2
C
Legs Quadro Loop x2
D
Beam x1
E
Plastic bracket x4
SCREWS
F
M8x20MM CSK x2
G
M8x20MM Socket head x2
H
M6x20MM Socket head x4
I
M6x30MM Socket head x4
J
Allen key x2
All manuals and user guides at all-guides.com
www.jasonl.com.au
Need help!
Call us on
1300 527 665
D
B
A
E
F
G
C
H
I
Page 2 of 6
