- Page 1 PA SERIES : Polycarbonate Awning Owner’s Manual For your safety and the safety of others, please read all of the instructions and warnings in this manual carefully before proceeding with assembly and usage.
-
Page 2: Table Of Contents
B: Work gloves C: Safety goggles Fig.1 DO NOT ATTEMPT to assemble or install if: D: Rain is in the forecast E: Wind is in the forecast F: You are tired or under the influence of drugs, medication or alcohol Fig.2 www.advaning.com... -
Page 3: Safety Instructions And Warnings
Ascertain that assistance is available to lift and secure in position. • Make certain that the installation substrate is adequate (the PA Series awning MUST be mounted to the main structural supports) studs, header board, or solid masonry 3-inch in thickness or greater. -
Page 4: Package Contents And Parts
Rubber Strip Gasket Front/Back Aluminum Bracket Polycarbonate to Bracket Bolt Set (Bolt, Gaskets, & Nut) Lag Screw Set for Wood Installs (Lag & Washer) Mounting Hardware Wall Rubber Strip Gasket Masonry Expansion Bolt, Part#: ZDA-WEB-R2 NOT INCLUDED / SOLD SEPARATELY Fig.4 www.advaning.com... -
Page 5: Tool Requirements
SUGGESTED TOOLS Marker / Pencil Scissors Level SILICONE 1/2" Wrench or Socket Wrench Rubber Mallet Small wood block Slow Curing Outdoor Silicone W.S.A. 15/64" or 1/4" Drill Bit/s for Wood Installs Drill Ladder/s OPTIONAL: Weather Stripping Adhesive Fig.5 www.advaning.com... -
Page 6: Awning Terminology
AWNING TERMINOLOGY AND LOCATION Fig.6 Awning Polycarbonate Sheet Awning Bracket Bracket Bolt Set Front/Back Rubber Strip Awning Front Bar Awning Back Bar Mounting Hardware (Lag or Expansion) Mounting Hardware Cap Silicone Seal or Wall Rubber Strip Gasket (select models only) www.advaning.com... -
Page 7: Pre-Installation Guide
Fig 7 Run length should be free & clear of any ob- structions along the en- tirety of planned awning length. Advaning highly recom- mends consulting with Side view a professional installer/ Roof, eave or overhang contractor who can best... -
Page 8: Awning Assembly
Rubber Strip Gasket. Join Awning Front/Back Bars to Fig 11 sheet pressing onto the Rubber Strip THIS SIDE UP Gasket edges. Ensure the Awning Front/ Back Bar are correctly oriented as illustrat- ed in fig. 11, labeled THIS SIDE UP. www.advaning.com... - Page 9 Ensure Ensure follow follow W.S.A. instructions & W.S.A. instructions & have a rag to wipe off have a rag to wipe off any excess. any excess. Fig 14 www.advaning.com...
-
Page 10: Awning Installation
CAUTION: DO NOT drill where electrical, gas, or water supply lines may exist. Fig 16 3 inch Wall Fig 17 www.advaning.com... - Page 11 (illustrated). NOTE: For solid ma- sonry instructions, please visit or request Wall detailed expansion bolt instructions via www.advaning.com Fig 19 Ensure to check the product is level be- fore securely tight- ening the mounting hardware. Securely tighten the lag screw with wrench/socket wrench.
- Page 12 & WEATHER PROOFING Wall Cover each screw with a Mount- Hardware Fig 22 by gently tapping in place with a rubber mallet. Apply a bead of slow curing outdoor sili- cone to the wall and Back Bar connection. Fig 23 www.advaning.com...
-
Page 13: Maintenance And Care
MAINTENANCE condition. Tighten and replace parts or reapply silicone as needed. All parts can be easily obtained from Advaning should there ever be a need for replacement. SNOW LOADS Although the awning is made to handle significant loads, we recommend clearing accumulated and packed snow whenever possible. -
Page 14: Warranty And Service
Should the original owner/purchaser submit a claim within the warranty period from the date of the purchase and after being deemed defective by Advaning, will the warranty claim be resolved by either of the following: A. Defective components are replaced (shipping charges may apply). - Page 15 3-days of signing for the delivery in order to make a claim. Likewise, there is a 7-day window from the time of delivery to report missing parts to Advaning. Failure to report shipping damage and missing parts in a timely manner and in accordance with the shipper/ carrier guidelines may result in the owner incurring all costs.
- Page 16 CONTACT Product Questions? Please contact Advaning via email at service@advaning.com, INFORMATION by phone at 714-622-2600, or by chat on our website; www.advaning.com Advaning Customer Service is available Monday through Friday from 8:30 a.m. to 4:00 p.m. PST www.advaning.com PA.OM.V04.112022...
