- Page 1 LUXURY SERIES Retractable Awning Owner’s Manual (Dual-Use Mounting Brackets) For your safety and the safety of others, please read all of the instructions and warnings in this manual carefully before proceeding with an installation and usage.
-
Page 2: Table Of Contents
CAUTION The awning arms contain tensioned cables. Always use caution, securely tie the awnings arms to the awning when performing installation, adjustments, or repairs. Sudden movement of tension arms can result in serious personal injury, product and/or property damage. www.advaning.com... -
Page 3: Safety Instructions And Warnings
FIRE, ELECTRIC SHOCK OR PERSONAL INJURY. Installation • Pay close attention throughout the installation process to ensure that the Advaning awning is installed properly and according to the safety guidelines outlined herein. • Do not attempt installation while under the influence of alcohol or drug substances. -
Page 4: Package Contents And Parts
-Wall Cradle Model 8’~10’ 12’~13’ 14’ 16’ -Wall Mount with screws Parts name Quantity Advaning awnings allow users to set a customized stop with the Motor Regulator. Wall/ ceiling Contact Advaning for custom- bracket ized stop setting instructions if Wall/ needed. -
Page 5: Tool Requirements
Masonry drill bit Drill with bits Fig.4 Ladders (2) PRODUCT FEATURES Arm shoulder Valance Cassette Powercord Fig.5 Crank loop Retractable arms Torsion bar Easy Pitch loop Roller tube Wall/ceiling bracket Awning fabric Lag screw Electric model only Front bar Retaining bolt www.advaning.com... -
Page 6: Installation
All brackets must be mounted onto Left awning shoulder wall studs or other major structural supports. Right awning shoulder 8 ~ 10 feet awning 12 ~ 13 feet awning 14 feet awning 16 feet awning Fig.6 www.advaning.com... -
Page 7: Determine Where To Install Your Awning
Side view Minimum 8 feet width. Roof, eave or overhang Minimum 1 inch Minimum 12 inch clear space Recommended 11 feet projection 8~10 feet Fig 8 Ground, floor or deck www.advaning.com... -
Page 8: Install Wall Brackets
Center of stud of the stud. Use a level to make Level sure the bracket is straight and mark the center of the mount- ing holes. 3.5” Drill mounting holes using a drill bit. Wall Fig 11 Fig 12 www.advaning.com... -
Page 9: Masonry Installation
Siding Fig 15 shims, cutting or drilling into your siding. Masonry installation For installing Advaning awning onto brick or solid concrete wall/surface. CAUTION: Always install brackets securely to the brick or concrete and not in the grout to avoid... - Page 10 Mark the center of the bracket mounting holes. Drill mounting holes using a masonry drill bit. Bracket Center Fig 18 Fig 19 3.5” Wall Fig 20 www.advaning.com...
- Page 11 Wall Bracket straight. Fig 23 Fig 24 Re-insert bolts into the holes through wall bracket. Tighten the hex bolts Tighten to secure wall bracket to surface. Hex bolt Wall Wall Bracket Bracket Fig 25 Fig 26 www.advaning.com...
-
Page 12: Install Ceiling Brackets
Use a level to make sure the bracket is Level straight and mark the center of the mount- ing holes. Drill mounting holes using a drill bit. Bracket Fig 29 Fig 30 www.advaning.com... -
Page 13: Install Awning Onto Brackets
Place retaining bolt into the bracket and use the nut and wash- er to secure bolt into Fig 34 place. Torsion bar Tighten the bolt with a socket wrench. Socket wrench Fig 35 www.advaning.com... -
Page 14: Ready Your Awning
Ensure the batteries come with a CR2430 Bat- (+) symbol faces out- tery. Genlty pull the plas- ward. tic tab so that your bat- CR2430 tery makes connection. Replace the battery Battery cover secure Battery with screw. cover Fig 38 www.advaning.com... -
Page 15: Operation
(close) the awning completely. Fig 40 Use the remote con- trol’s stop button (center) to stop the awning at a desired extension. Contact Advaning for re- mote control re-synch or Remote customized stop setting control instructions if needed. www.advaning.com... -
Page 16: Fabric Rolling Direction
Fabric Fully open the awning and with the use of a level ensure the front EXTEND OUT FULLY bar is straight and MAKE ADJUSTMENT UP OR DOWN EXAMPLE OF LOWERED PITCH EXTEND OUT 1/3 OR 2FT leveled. Fig 43 www.advaning.com... -
Page 17: Maintenance
CLEANING CARE To clean your Advaning awning, lower pitch via the Easy Pitch™ loops and open awning completely to see and access the top of the awning and allow proper water drainage. Use a mild soap and water mix (1 part soap to 2 parts water) and standard garden hose to gently remove any accumulated dust, dirt, or debris. -
Page 18: Warranty
Should the purchaser notify Advaning within the twenty-four (24) months or two (2) year period from the date of the original purchase, Advaning will ship out replacement part at no charge. Advaning reserves the right to ask for the defective component to be returned and/or photos/videos of the defective component. - Page 19 Some states do not allow limitations on how long an implied warranty lasts, so the above limitation may not apply to you. UNDER NO CIRCUMSTANCES SHALL ADVANING, INCLUDING ITS SUBSIDIARIES AND AFFILIATES BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES WITH RESPECT TO ECONOMIC LOSS, INJURY, DEATH OR PROPERTY DAMAGE, WHETHER AS A RESULT OF BREACH OF THIS WARRANTY, NEGLIGENCE OR OTHERWISE.
- Page 20 CONTACT Service Questions: service@advaning.com INFORMATION 12282 Knott Street, Garden Grove, CA 92841 www.advaning.com OM_L Series_Dual_V06_R02.2021.09.21...
