READ AND SAVE THESE INSTRUCTIONS
INSTALLATION INSTRUCTIONS
Model: AC-19752
KENDAL LIGHTING
Kendal Lighting (BC) Inc.
#110, 6780 Dennett Place
Delta, BC V4G 1N4
Canada
Tel: (604) 952-5510
Fax: (604) 952-5513
C.E.T.L. LISTED MODEL: CF552B
Weight of Fan: 9.02Kgs

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AC-19752 and is the answer not in the manual?

Questions and answers

Related Manuals for Kendal Lighting AC-19752

Summary of Contents for Kendal Lighting AC-19752

  • Page 1 READ AND SAVE THESE INSTRUCTIONS INSTALLATION INSTRUCTIONS Model: AC-19752 KENDAL LIGHTING Kendal Lighting (BC) Inc. #110, 6780 Dennett Place Delta, BC V4G 1N4 Canada Tel: (604) 952-5510 Fax: (604) 952-5513 C.E.T.L. LISTED MODEL: CF552B Weight of Fan: 9.02Kgs...

  • Page 2: Tools And Materials Required

    1. TOOLS AND MATERIALS REQUIRED Philips screw driver Blade screw driver 11 mm wrench Step ladder Wire cutters 2. PACKAGE CONTENTS Unpack your fan and check the contents. You should have the following items; a. Hanger bracket b. Canopy c. Canopy cover d.

  • Page 3: Safety Rules

    3. SAFETY RULES 1. To reduce the risk of electric shock, insure 8. Avoid placing objects in the path of the electricity has been turned off at the circuit blades. breaker or fuse box before beginning. 9. To avoid personal injury or damage to the 2.

  • Page 4: Mounting Options

    4. MOUNTING OPTIONS If there isn't an existing CUL listed mounting box, then read the following instructions. Disconnect the power by removing fuses or turning off circuit breakers. Outlet box Secure the outlet box directly to the building structure. Use appropriate fasteners and building materials.

  • Page 5: Hanging The Fan

    5. HANGING THE FAN REMEMBER to turn off the power. Follow the steps below to hang your fan properly: Step 1. Pass the 120-volt supply wires through CUL Listed electrial the center hole in the ceiling hanger bracket as shown in Fig. 5. Washers Ceiling Step 2.

  • Page 6: Make The Electric Connections

    6. MAKE THE ELECTRIC CONNECTIONS Code switch WARNING: To avoid possible electrical shock, be sure electricity is turned off at the main fuse box before wiring. NOTE: This remote control unit is equipped with 16 code combinations to prevent possible Figure 8 interference from or to other remote units.

  • Page 7: Finishing The Installation

    Note: Fan must be installed at a maximum distance of 20 feet from the transmitting unit for proper signal transmission between the transmitting unit and the fan's receiving unit. 7. INSTALLATION OF SAFETY CABLE An additional safety cable is provided to prevent the fan from falling.

  • Page 8: Attaching The Fan Blades

    9. ATTACHING THE FAN BLADES Screws Fiber washers Step 1. Attach the fan blades to the blade holders Blade holder by using three screws and fiber washers as shown in Figure 13. Start a screw into the blade holder, do not tighten. Repeat for the 2 remaining screws and washers.
  • Page 9 11. ATTACHING THE LIGHT KIT ASSEMBLY NOTE: Before starting installation, disconnect the power by turning off the circuit breaker or Light kit removing the fuse at fuse box. Turning power plate Screw off using the fan switch is not sufficient to prevent electric shock.
  • Page 10 13. INSTALLING THE Outlet box TRANSMITTER Switch HOLDER Wall plate Select a location to install your remote control system transmitter. You can replace an existing wall switch or, install the transmitter on ANY flat surface. Option 1: Install the remote c ontrol system using an existing wall switch outlet box.

  • Page 11: Installing The Battery

    14. INSTALLING THE BATTERY Remove the back cover on the transmitter and install both, 3 volt (#2032) batteries that were included with the remote control. Make sure the + sign is facing up. (Fig. 23) 15. OPERATING YOUR TRANSMITTER Figure 23 Restore power to ceiling fan and test for proper operation.

  • Page 12: Care Of Your Fan

    16. CARE OF YOUR FAN Here are some suggestions to help you maintain your fan. 1. Because of the fan's natural movement, some connections may become loose. Check the support connections, brackets, and blade attachments twice a year. Make sure they are secure.

  • Page 13: Troubleshooting

    17. TROUBLESHOOTING Problem Solution Fan will not start. 1. Check main and branch circuit fuses or breakers. 2. Check line wire connections to the fan and switch wire connections in the switch housing. 3. Check to make sure the dip switches from the transmitter and receiver are set to the same frequency.
