Ceiling Fan
Installation Instructions
Model #: AC-12452
Please Read and Save

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AC-12452 and is the answer not in the manual?

Questions and answers

Related Manuals for Kendal Lighting AC-12452

Summary of Contents for Kendal Lighting AC-12452

  • Page 1 Ceiling Fan Installation Instructions Model #: AC-12452 Please Read and Save...

  • Page 2: Tools And Materials Required

    1. TOOLS AND MATERIALS REQUIRED Philips screw driver Blade screw driver 11 mm wrench Step ladder Wire cutters 2. PACKAGE CONTENTS Unpack your fan and check the contents. You should have the following items; Blade set (5) Hanger bracket Canopy Downrod Coupling cover Fan motor assembly...

  • Page 3: Safety Rules

    3. SAFETY RULES To reduce the risk of electric shock, insure To avoid personal injury or damage to the fan electricity has been turned off at the circuit and other items, be cautious when working breaker or fuse box before beginning. around or cleaning the fan.

  • Page 4: Mounting Options

    4. MOUNTING OPTIONS If there isn't an existing CUL listed mounting box, then read the following instructions. Disconnect the power by removing fuses or turning off circuit breakers. Outlet box Secure the outlet box directly to the building structure. Use appropriate fasteners and building materials.
  • Page 5 5. Hanging the Fan REMEMBER to turn off the power. Follow the steps CUL Listed electrial below to hang your fan properly: NOTE: This ceiling fan is supplied with two types of hanging assemblies; the standard ceiling Ceiling Washers mounting installation using the downrod with ball and socket plate mounting and the "close-to-ceiling"...
  • Page 6 CLOSE-TO-CEILING INSTALLATION 1. Remove the decorative canopy bottom cover Canopy from the canopy by depressing the three studs (Fig. 8) Canopy bottom cover 2. Pass the 120-volt supply wires through the center hole in the ceiling hanger bracket as Figure 8 shown in Fig.

  • Page 7: Installation Of Safety Support

    6. INSTALLATION OF SAFETY SUPPORT Hanger bracket An additional safety support is provided to prevent Safety cable the fan from falling. Secure the safety cable to the ceiling joist with screw and washer, as illustrated in Figure 11. Figure 11 7.
  • Page 8 Step 3. (Fig. 14 and 15) Receiver to house supply Outlet box wires electrical connections: Connect the black (hot) wire from the ceiling to the black wire marked "AC White (neutral) Black (hot) in L" from the receiver. Connect the white(neutral) Green or bare wire from the ceiling to the white wire marked "AC copper (ground)

  • Page 9: Installing The Wall Transmitter

    8. INSTALLING THE WALL TRANSMITTER WARNING! HOOK UP "IN SERIES" ONLY. DO NOT CONNECT NEUTRAL SUPPLY WIRE OF ELECTRIC CIRCUIT TO THE TRANSMITTER WALL SWITCH, DAMAGE TRANSMITTER WALL SWITCH AND POSSIBLE FIRE COULD OCCUR. Step 1. Remove the existing wall plate and switch from the wall outlet box.

  • Page 10: Attaching The Fan Blades

    10. ATTACHING THE FAN BLADES Step 1 Attach the blade to the blade bracket using the screws and fiber washers as shown in Figure Screws Fiber 19. Start screw into bracket. Repeat for the two washers remaining screws. Step 2 Tighten each screw. Make sure the blade is straight.
  • Page 11 12. ATTACHING THE LIGHT PLATE NOTE: Before starting installation, disconnect the power by turning off the circuit breaker or removing the fuse at fuse box. Turning power off using the fan switch is not sufficient to prevent electric shock. Step 1. Raise and hold the light kit close to the mounting plate and proceed to do the wire Mounting plate...
  • Page 12 14. OPERATING INSTRUCTIONS Restore power to ceiling fan and test for proper operation. HI HI A. HI, MED, and LOW buttons: LIGHT LIGHT These three buttons are used to set the fan speed as follows: HI= high speed Med= medium speed FAN OFF FAN OFF Low= low speed...

  • Page 13: Troubleshooting

    15. TROUBLESHOOTING Problem Solution Fan will not start. 1. Check circuit fuses or breakers. 2. Check line wire connections to the fan and switch wire connections in the switch housing. CAUTION: Make sure main power is off. 3. Check to make sure the dip switches from the transmitter and receiver are set to the same frequency.
