READ AND SAVE THESE INSTRUCTIONS
INSTALLATION INSTRUCTIONS
Model: AC11152P-ORB/WN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AC11152P-ORB/WN and is the answer not in the manual?

Questions and answers

Related Manuals for Kendal Lighting AC11152P-ORB/WN

Summary of Contents for Kendal Lighting AC11152P-ORB/WN

  • Page 1 READ AND SAVE THESE INSTRUCTIONS INSTALLATION INSTRUCTIONS Model: AC11152P-ORB/WN...

  • Page 2: Tools And Materials Required

    1. TOOLS AND MATERIALS REQUIRED Philips screw driver Blade screw driver 11 mm wrench Step ladder Wire cutters 2. PACKAGE CONTENTS Unpack your fan and check the contents. You should have the following items; Blade set (5) Hanger bracket Canopy Downrod Coupling cover Fan motor assembly...

  • Page 3: Safety Rules

    3. SAFETY RULES To reduce the risk of electric shock, insure Do not operate the reverse switch while the fan electricity has been turned off at the circuit blades are in motion. The fan must be turned breaker or fuse box before beginning. off and the blades stopped before reversing the blades direction.

  • Page 4: Mounting Options

    4. MOUNTING OPTIONS If there isn't an existing CUL listed mounting box, then read the following instructions. Disconnect the power by removing fuses or turning off circuit breakers. Outlet box Secure the outlet box directly to the building structure. Use appropriate fasteners and building materials.

  • Page 5: Hanging The Fan

    5. HANGING THE FAN CUL Listed REMEMBER to turn off the power. Follow the steps electrial below to hang your fan properly: NOTE: This ceiling fan is supplied with two types of Ceiling Washers hanging assemblies; the standard ceiling mounting installation using the downrod with ball and socket plate mounting and the "close-to-ceiling"...
  • Page 6 CLOSE-TO-CEILING INSTALLATION Canopy 1. Remove the decorative canopy bottom cover from the canopy by depressing the three studs (Fig. 8) Canopy bottom cover 2. Pass the 120-volt supply wires through the center hole in the ceiling hanger bracket as Figure 8 shown in Fig.

  • Page 7: Installation Of Safety Support

    6. INSTALLATION OF SAFETY SUPPORT An additional safety support is provided to prevent Hanger bracket the fan from falling. Secure the safety cable to the Safety cable ceiling joist with screw and washer, as illustrated in Figure 11. 7. MAKE THE ELECTRIC Figure 11 CONNECTIONS Remember to disconnect the power.
  • Page 8 WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR OTHER PERSONAL POWER LINES 120V INJURY. MOUNT FAN ONLY ON AN OUTLET LIGHT BOX OR SUPPORTING SYSTEM MARKED GREEN GROUND ACCEPTABLE FOR FAN SUPPORT. WIRING GROUND TO MOUNTING BRACKET OR DOWNROD 8.

  • Page 9: Attaching The Fan Blades

    9. ATTACHING THE FAN BLADES CAUTION: Remove 5 rubber packing mounts and discard before installation. Step 1 Attach the blade to the blade bracket using the screws and fiber washers as shown in Figure 17. Start screw into bracket. Repeat for the two remaining screws.
  • Page 10 11. OPERATING INSTRUCTIONS NOTE: Wait for fan to stop before changing the setting of the slide switch. Turn on the power and check the operation of your fan. 1. 3-speed pull chain- it controls the fan speed as follows: 1 pull- High, 2 pulls- Medium, 3 pulls- Low, and 4 pulls- Off.

  • Page 11: Troubleshooting

    12. TROUBLESHOOTING Problem Solution Fan will not start. 1. Check circuit fuses or breakers. 2. Check line wire connections to the fan and switch wire connections in the switch housing. CAUTION: Make sure main power is off. Fan sounds noisy. 1.
