Chapter 3 – Software Installation
Introduction
Configuring software for your MultiVOIP entails three tasks:
Loading the software onto the PC (this is "Software Installation" and is discussed in this chapter).
Setting values for telephony and IP parameters that will fit your system (details are in Chapter 4).
Establishing "phonebooks" that contain the various dialing patterns for VOIP calls made to different locations (a
detailed discussion of this is found in Chapter 5).
Loading MultiVOIP Software onto the PC
The software loading procedure does not present every screen or option in the loading process. It is assumed that
someone with a thorough knowledge of Windows and the software loading process is performing the installation.
1. Be sure that your MultiVOIP has been properly cabled and that the power is turned on.
2. Insert the MultiVOIP CD into your CD-ROM drive. The CD starts automatically. It may take a few moments for
the Multi-Tech CD installation window to display.
Figure 3-1: splash screen
3. When the Multi-Tech Installation CD dialog box appears, click the Install Software icon.
Multi-Tech Systems, Inc.
10
