Web Management Software Opens

The Web Management software Home screen displays.
This software is factory-installed on your RouteFinder.
A description of the Web Management software continues in Chapter 4.
Before using the software, you may find the following information about navigating the screens and the
structuring of the menus helpful.

Navigating Through the Software Screens

Menu
Bar
Sub
Menu
RouteFinder Menu Bar
Sub-Menu
Each item on the Menu Bar has its own sub-menu, which displays on the left side of the screen.
When you click one of the Menu Bar buttons, the first sub-menu option displays. You can choose other
sub-menu screens by clicking the screen name in the sub-menu list.
This is an example of the Networks & Services sub-menu.
Multi-Tech Systems, Inc. RouteFinder RF850/860 User Guide (PN S000400E)
(This is a view of the top part of the Home screen.)
Chapter 2 – Installation and Setup
Other
Options
Screen
Name
Input /
Display
Area
19
