TWL-C-M User's Manual
6. Technical Specifications
Operating Wavelength
Wavelength Accuracy
Wavelength Stability
Output Power
Output Stability
Linewidth (FWHM)
Carrier to Noise Ratio (CNR)
Side Mode Suppression Ratio
Relative Intensity Noise (RIN)
Polarization Extinction Ratio
Optical Isolation
Fiber Type
7. Mechanical Specifications
Power Supply Requirements
Optical Connectors
Operating Temperature
Storage Temperature
Control
Communication Interface
Dimensions
Optilab, LLC
600 E. Camelback Road, Phoenix, AZ 85012
Phone: (602) 343-1496, Fax: (602) 343-1489, Email: sales@oequest.com
Optical Specifications
1527.6nm to 1567.13nm
± 1.5 GHz
± 1pm over 24 hours
50mW max.
0.02 dB over 8 hours
< 10 kHz w/o SBS
< 750 MHz w/ SBS
50 dBc typ. @ -5 dBm
55 dB typ.
-145dB/Hz
20 dB min.
30 dB min.
Panda 1550 PM Fiber
100-240 VAC
PM Narrow Key FC/APC
Standard, additional types available
0°C to +40°C
-40°C to +70°C
Output Power Level, Wavelength
RS232, via DB9 serial or USB 2.0
120mm x 112mm x 32mm
Page 14 of 16
