2.4. Operation Instructions

Start-up Procedure
1. Insert the AC power cord into an appropriate AC power supply source and the
power supply AC Power Socket on the TWL-C-M unit.
2. Make the proper PC communication port connection, either USB or DB9 via serial
cable, ensuring the communication switch is set to the intended primary control
method.
3. To ensure proper remote communication, ensure the Laser Enable button is in the
enabled (inward) position prior to switching the AC Power Switch to the on
position.
4. Once all proper communication and optical connections are made, enable the rear
panel AC Power Switch to the On position; the Power LED should enable green
on the DC supply (blue on the TWL unit), and the Laser LED should also enable
green (blue on the TWL unit).
5. The TWL-C-M unit is now fully operational; please refer to the Software Interface
and Control section for more adjustment and operation details.
Patchcord Swapping Procedure
1. Toggle the AC Power Switch to the OFF position to disable the TWL-C-M module
output.
2. Swap patchcords as desired. Only connect the indicated connector patchcords to
the optical input/output receptacles, cleaning them as necessary.
3. Toggle the AC Power Switch to the ON position; refer back to the Start-Up
procedure to resume operation.
