TWL-C-M User's Manual

3.2. General

This is first tab of software for connection between software and TWL-C-M unit
through RS232.
1
3
C
OMMAND
① COM P
S
ORT ETTING
② D
I
EVICE NFORMATION
③ C
/E
LOSE XIT
Optilab, LLC
600 E. Camelback Road, Phoenix, AZ 85012
Phone: (602) 343-1496, Fax: (602) 343-1489, Email: sales@oequest.com
2
<General Tab>
Select the appropriate COM Port for the TWL-C-M. Then click
'Connect' to connect
Please 'Refresh' if your COM port is not listed
'Device Information' section will be activated if RS232
connection has been successfully completed. It read & display
information from laser.
'Close' button will disconnect RS232 connection.
'Exit' button will close application completely.
D
ESCRIPTION
Page 8 of 16
