TWL-4-B-MIC User's Manual

3. Technical Specifications

Optical Specifications
Operating Wavelength
Optical Output Level
Laser linewidth (FWHM)
Electrical and Mechanical Specifications
Power Supply Requirements
Optical Connectors
Output Fiber
Operating Temperature
Storage Temperature
Control
Power Consumption
Optilab, LLC
600 E. Camelback Road, Phoenix, AZ 85012
Phone: 1-602-343-1496, Fax: (602) 343-1489, Email: sales@oequest.com
1528 nm to 1565 nm tunable
5 to 20 mW adjustable
100 kHz (Under low noise mode)
100 to 240 VAC, 50/60 Hz
FC/APC
Panda PM-15
10°C to +40°C (Standard)
-20°C to +70°C
LCD touch screen, USB
25 W (Max)
Page 9 of 11
