TWL-4-B-MIC User's Manual

1. General Information

1.1 SAFETY PRECAUTIONS

This product emits medium laser radiation from the optical connector(s) that classifies
it to be a CLASS 1M
output is hazardous for eyes exposure.
radiation.
The optical output must be disabled when swapping patch-cord connections.
Ensure the optical output is within the range specified in the test report.

1.2 Introduction

This manual contains information on the operation of the TWL-4-B-MIC
unit.

1.3 Product Overview

The Optilab TWL-4-B-MIC is a 4 channel C band narrow linewidth
tunable laser benchtop. The laser unit contains four external cavity laser
diodes each driven by its low noise laser driver. The TWL-4-B-MIC
provides up to 20 mW CW optical power in the 1528 nm - 1565 nm
wavelength region for each channel. The TWL-4-B-MIC can be set to
work at low noise mode, and the laser linewidth width can be as narrow
as sub-100 kHz. The laser output can be controlled through the LCD
touch screen or remotely through a PC. Please contact Optilab for more
information.

1.4 Features

•
Four channel outputs
•
External cavity laser diode
•
Narrow linewidth
•
1528 nm to 1565 nm tunable laser wavelength
•
5 to 20 mW tunable laser output power
•
LCD touch screen monitor and remote control
Optilab, LLC
600 E. Camelback Road, Phoenix, AZ 85012
Phone: 1-602-343-1496, Fax: (602) 343-1489, Email: sales@oequest.com
laser product accordingly to IEC 60825-1:2014. The optical
Avoid eye exposure to direct or scattered
