Cree XLamp XR Series Soldering & Handling

Cree Xlamp
®
inTroduCTion
This application note applies to XLamp
LeDs, which have order codes in the following fomat.
Xrxxxx-xx-xxxx-xxxxxx
This application note explains how XLamp Xr family
LeDs and assemblies containing these LeDs should be
handled during manufacturing. Please read the entire
document to understand how to properly handle
XLamp Xr family LeDs.
