Catalogue(EN) Vehicle display Name of major parts Safety instruction Product introduction Unfolding/ pic Foldingl pic Basic operations Display Brake Riding operations Start Riding Stop riding Battery and charger Maintenance Lubrication Tire Brake General troubleshooting Parameter table Warranty... -
Page 4: Vehicle Display
Vehicle display... -
Page 5: Name Of Major Parts
Name of major parts Display Brake lever Handle bar Ront light switch Quick release clamp Seat Front tube Rear fender Front light Rear motor Disc brake pad Suspension charger port... -
Page 6: Safety Instruction
SAFETY INSTRUCTION 1、This product is suitable for adults which can be used only by one person. 2、Please wear the helmet and other protective equipment when you are riding. 3、Please ride on the road safely and legally. 4、Practice before riding. 5、Be careful and safe; Both hands and feet should be keep on the scooter. 6、Don't turn off the power when you are riding. -
Page 7: Product Introduction
Product introduction Unfolding pic step1: press the foiding clamp to unfold the scooter step2: lock the folding lever... - Page 8 step3: Expand the handlebar upward,keep the handlebar straight step4: Adjust the handlebar to the suitable height.Tighten the quick release clamp.
-
Page 9: Foldingl Pic
Folding pic step1: pull the sleeve out and fold down the handlebar. step2: Release the quick release on the front tube. press down the handlebar to the bottom... - Page 10 step3: pull out the folding lever,pull the folding clamp,fold down thefront tube...
-
Page 11: Basic Operations
Basic operations Display Picture: 1. power switch 2. mode switch 3. thumb throttle 4. power display 5. speed display 6. mileage display 1 . power switch 1.1 In power off status,press the button for 3 seconds,the display works.Keep the scooter on for 5 minutes without any operation, it will turn off automatically 1.2 ln the power on status, press for 3 seconds, the device will... -
Page 12: Brake
Brake Please avoid urgently braking, it will cause the tire broken and slip down. Riding operation Start 1. Practice outside, choose good road condition. 2. Open the scooter according to the user manual. 3. Adjust the height of the handlebar to your suitable height. 4. -
Page 13: Battery And Charger
BATTERY AND CHARGER Each scooter has its own battery and charger,each part has different serial number. Please do not charger the scooter with other brands" chargers. Battery Please charge your scooter when you get this scooter, it is better to take your scooter full charged before riding. -
Page 14: Maintenance
Maintenance Lubrication Add some lubricant on the folding part of the handlebar every 6 months,keep the handlebar working smoothly. Note: Do not add the WD40 on the scooter. Do not add any lubricant on the front and rear whell. Tire Both front and rear tires are pneumatic tires,if it is broken obvious- ly,please contact the distributor to replace them. -
Page 15: Parameter Table
Parameter table Unfolding size 1160*600*1370mm Folding size 1160*200* 460mm SPECIFICATION N.W. 24.5Kg Maximum load 150Kg Maximum speed 25KM/h Climbing ability 15-25° PERFORMANCE Rated voltage Distance 35-40KM Capacity 15AH BATTERY Type Lithium battery Motor type Brushless DC motor Rated power output 9.5 N.m MOTOR Maximum speed... -
Page 16: Warranty
WARRENTY Any of the parts in the following sheet occurs failure in normal use, please contact us, we will provide complete after-sale service. Quality Warranty Parts service description period Failure occurs in Free Motor 2 year normal use maintenance Failure occurs in Free Controller 6 months... - Page 17 Warranty invalid if caused by the following reasons: 1. Haven't do maintenance according to this manual. 2. Parts broken caused by playing or some dangerous actions. 3. Disassembling and assembling by users or use the other brand's parts in this scooter. Parts broken cause by traffic accident or stroke by user.
