- Page 1 Signamax™ FO-065-1200 series 12-Port Media Converter ™ Signamax Connectivity Systems FO-065-7110 Series Compact Fiber Access Switch ’ S E R U I D E User’s Manual...
- Page 2 ™ Signamax Connectivity Systems F0-065-7110 Series Compact Fiber Access Switch User’s Guide...
-
Page 3: Fcc Statement
Signamax™ 065-7110 series Compact Fiber Access Switch FCC Statement The FCC (Federal Communications Commission) restricts the amount of radio frequency emission and radiation coming from computer equipment. Ethernet switch stated in this manual has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC rules. -
Page 4: Preface
Signamax™ 065-7110 series Compact Fiber Access Switch Preface ™ This manual describes how to install and use the Signamax 065-7110 series Compact Fiber Access Switch, with seven auto-negotiating and auto-MDIX 10/100BaseT/TX ports plus one 100BaseFX 100 Mbps fiber port. To get the most out of this manual, it is suggested that you have prior knowledge of networking concepts such as bridging, IEEE 802.3 Ethernet, IEEE 802.3u 100BaseTX/FX Fast... -
Page 5: Table Of Contents
Signamax™ 065-7110 series Compact Fiber Access Switch Table of Contents FCC Statement............1 Preface..............2 Introduction............. 4 Ethernet Switch ............4 Product Features ............5 Packing List...............5 Front Panel ...............6 Ports....................6 LEDs .....................7 Installation .............. 9 Selecting a Site for the Switch ........9 Connecting to Power.......... -
Page 6: Introduction
Signamax™ 065-7110 series Compact Fiber Access Switch Introduction Ethernet Switch ™ The Signamax 065-7110 Compact Fiber Access Switch provided is an eight-port Fast Ethernet switch. The switch has seven 10/100BaseT/TX ports with RJ-45 connectors and one 100BaseFX port with fiber connector. Each 10/100BaseT/TX port is capable of auto sensing speed, half/full duplex modes, and auto-MDIX. -
Page 7: Product Features
Signamax™ 065-7110 series Compact Fiber Access Switch The Ethernet switch facilitates an affordable and efficient migration path to 100Mbps Fast Ethernet and can continue to enhance your network's performance even if you upgrade your existing network with standard Ethernet applications, internetworking systems, and client-side adapters to minimize migration costs. -
Page 8: Front Panel
Signamax™ 065-7110 series Compact Fiber Access Switch Front Panel ™ The front panel of the Signamax 065-7110 switch has eight ports and an array of LED indicators to provide you with instant feedback on the status of the switch. Figure 1: Front Panel of your switch... -
Page 9: Leds
Signamax™ 065-7110 series Compact Fiber Access Switch The following table summarizes the port and cable specifications for the switch: Speed Connector Port Speed Cable Half/Full Duplex 10BaseT RJ-45 10/20 Mbps 100 m, Category 3, 4, or 5 UTP 100BaseTX RJ-45... - Page 10 Signamax™ 065-7110 series Compact Fiber Access Switch Œ Port Status Each port has an array of three LEDs that show the status of the port. The LEDs are identified by corresponding captions located below the LEDs on the front panel.
-
Page 11: Installation
Signamax™ 065-7110 series Compact Fiber Access Switch Installation This chapter presents step-by-step installation instructions for the enclosed Ethernet switch. Selecting a Site for the Switch As with any electronic device, you should place the switch where it will not be subject to extreme temperatures, humidity, or electromagnetic interference. -
Page 12: Connecting To Power
Signamax™ 065-7110 series Compact Fiber Access Switch Connecting to Power Connect the supplied AC power cord to the receptacle on the back of the switch, and then plug the cord into a standard AC outlet with a voltage range from 100 to 240 VAC. -
Page 13: Specifications
Signamax™ 065-7110 series Compact Fiber Access Switch Specifications Signamax™ 065-7110 series Compact Fiber Access Switch -- Seven 10/100BaseT/TX auto-negotiating ports with RJ-45 connectors plus one 100BaseFX port with fiber connector. 10BaseT, IEEE 802.3 Applicable Standards 100BaseTX/FX, IEEE 802.3u Per unit – Power Status LED Indicators Per Port –... -
Page 14: Ordering Information
Signamax™ 065-7110 series Compact Fiber Access Switch Ordering Information FO-065-7110SC 7 Port 10/100BaseT/TX + 1 Port 100BaseFX SC Multimode Switch FO-065-7110ST 7 Port 10/100BaseT/TX + 1 Port 100BaseFX ST Multimode Switch FO-065-7110MT 7 Port 10/100BaseT/TX + 1 Port 100BaseFX MT-RJ Multimode Switch... -
Page 15: Contact Information
Signamax™ 065-7110 series Compact Fiber Access Switch Contact Information SIGNAMAX™ CONNECTIVITY SYSTEMS An AESP Company 1810 N.E. 144th Street. North Miami, Florida 33181, U.S.A. Phone: 305-944-7710 Fax: 305-652-8489 Sales: 800-446-2377 Tech. Support: 800-446-2377, ext. 201 Http://www.signamax.com E-mail: info@signamax.com EUROPE AESP Ukraine. (UKRAINE) AESP Russia.
