- Page 1 Signamax™ FO-065-1200 series 12-Port Media Converter ™ Signamax Connectivity Systems FO-065-7030Q 16-Port QoS Switch ’ S E R U I D E User’s Manual...
- Page 2 ™ Signamax Connectivity Systems F0-065-7030Q 16-Port QoS Switch User’s Guide...
- Page 3 ™ Signamax 065-7030Q 16-Port QoS Switch F C C S t a t e m e n t The FCC (Federal Communications Commission) restricts the amount of radio frequency emission and radiation coming from computer equipment. The equipment introduced in this manual has been tested and found to comply with the limits for a Class A digital device pursuant to Part 15 of the FCC rules.
- Page 4 065-7030Q 16-Port QoS Switch P r e f a c e This manual describes how to install and use the Signamax ™ 065- 7030Q 16-Port QoS Switch. The switch introduced here auto- negotiates the presence of 10/100Mbps and full/half-duplex mode.
- Page 5 ™ Signamax 065-7030Q 16-Port QoS Switch T a b l e o f C o n t e n t s FCC S TATEMENT RADEMARKS REFACE ABLE OF ONTENTS RODUCT VERVIEW RONT ACKAGE ONTENTS RODUCT EATURES RONT ANEL ISPLAY HYSICAL...
- Page 6 ™ Signamax 065-7030Q 16-Port QoS Switch THERNET ECHNOLOGIES Fast Ethernet Gigabit Ethernet THERNET RODUCTS Switch C – VLAN PPENDIX D– T PPENDIX ROUBLESHOOTING UIDE OWER TO THE WITCH LED F OWER AILURE ONNECTIVITY TO THE ERMINAL QUIPMENT ONNECTIVITY TO ERTAIN...
- Page 7 065-7030Q 16-Port QoS Switch P r o d u c t O v e r v i e w Front View Figure 1: Signamax™ 065-7030Q 16-Port QoS Switch Package Contents When you unpack the product package, you shall find these items listed below.
- Page 8 ™ Signamax 065-7030Q 16-Port QoS Switch Product Features ♦ ♦ 16 × 10/100M RJ-45 ROVIDES BPS PORTS USING CONNECTORS ♦ 16 RJ-45 MDIX. UPPORTS CONNECTOR PORTS WITH ♦ 16K MAC 16-P UPPORTS ADDRESSES FOR THE WITCH ♦ NEGOTIATION FOR SPEED AND DUPLEX MODE ON PORTS ♦...
- Page 9 • Ž Power Port Status Status Figure 2: Signamax™ 065-7030Q 16-Port QoS Switch Front Panel LEDs Œ Power This LED comes on when the switch is properly connected to power and turned on. • Port Status The RJ-45 ports numbered from 1 to 16 in one section on the 16-Port QoS Switch.
- Page 10 ™ Signamax 065-7030Q 16-Port QoS Switch Physical Ports The Signamax™ 065-7030Q 16-Port QoS Switch has sixteen 10/100Mbps ports using RJ-45 connectors with Auto MDIX function. NDERSTANDING RONT ANEL ESIGN Power LED Power feeding in Power switched off Improper connection Port LED...
- Page 11 ™ Signamax 065-7030Q 16-Port QoS Switch QoS (Quality of Service) Settings Figure 3: Default Setting of the QoS (Quality of Service) DIP Switch on the Rear Panel There are eight pins on the QoS (Quality of Service) DIP Switch for QoS (Quality of Service) Settings.
- Page 12 I n s t a l l a t i o n Selecting a Site for the Equipment As with any electric device, you should place the Signamax™ 065- 7030Q 16-Port QoS Switch where it will not be subjected to extreme temperatures, humidity, or electromagnetic interference.
- Page 13 Locate the power ON/OFF switch beside the receptacle at the back. Turn on the switch by flipping the ON/OFF switch to ON position. The power LED on the front panel will come on then. Figure 4: Rear view of the Signamax™ 065-7030Q 16-Port QoS Switch User’s Manual...
- Page 14 ™ Signamax 065-7030Q 16-Port QoS Switch Connecting to Your Network ABLING Step 1: First, ensure the power of the switch and end devices is turned off. It may cause an electric shock and possible harm to you if the power is not switched off.
- Page 15 ™ Signamax 065-7030Q 16-Port QoS Switch ETWORK EGMENTATION Cable Specifications Table Ethernet Connector Port Cable Max. Standards Speed Distance Half/Full Duplex 10Base2 10/20 Coaxial 185 m Mbps 10BaseT RJ-45 10/20 Cat. 3, 4 or 100 m Mbps 5 UTP/STP 100BaseTX...
- Page 16 ™ Signamax 065-7030Q 16-Port QoS Switch T e c h n i c a l S p e c i f i c a t i o n s ™ Signamax 065-7030Q 16-Port QoS Switch Applicable IEEE 802.3 10BaseT Standards IEEE 802.3u 100BaseTX...
- Page 17 ™ Signamax 065-7030Q 16-Port QoS Switch P h y s i c a l S p e c i f i c a t i o n s ™ Signamax 065-7030Q 16-Port QoS Switch Dimensions 254 × 135 × 35 mm (10 × 5.3 × 1.4 inch)
- Page 18 ™ Signamax 065-7030Q 16-Port QoS Switch A p p e n d i x A – C o n n e c t o r P i n o u t s Pin arrangement of RJ-45 connectors: Figure 5: RJ-45 Connector and Cable Pins The following table lists the pinout of 10/100BaseT/TX ports.
- Page 19 ™ Signamax 065-7030Q 16-Port QoS Switch A p p e n d i x B – I n t r o d u c t i o n t o L A N & E t h e r n e t T e c h n o l o g i e s...
- Page 20 ™ Signamax 065-7030Q 16-Port QoS Switch Ethernet Technologies More than 80 percent of all LANs utilize Ethernet technology. The Institute of Electrical and Electronic Engineers (IEEE) standardized Ethernet in IEEE 802.3, which provides for c onfiguration rules, interaction requirements, types of media, and data rate.
- Page 21 ™ Signamax 065-7030Q 16-Port QoS Switch Ethernet Products One of the earlier connection solutions for Ethernet, a hub (also called a repeater) operates by broadcasting data to all ports simultaneously, only to repeat it when it is not received. The hub works through a “shared network”...
- Page 22 ™ Signamax 065-7030Q 16-Port QoS Switch A p p e n d i x C – V L A N s Virtual local area network (VLAN) is a network configuration in which nodes are grouped into logical rather than physical networks.
- Page 23 VLAN identified. The switch receiving such a packet must be capable of identifying this information (known as a 802.1Q VLAN tag). The Signamax™ 065-7030Q 16-port desktop switch is capable of reading and interpreting this information. This feature allows it to be used in multi-switch environments where this capability is required.
- Page 24 ™ Signamax 065-7030Q 16-Port QoS Switch A p p e n d i x D – T r o u b l e s h o o t i n g G u i d e This section is to help you diagnosing common switch problems.
- Page 25 ™ Signamax 065-7030Q 16-Port QoS Switch No Power to the Switch Symptom: Power LED does not come up when the power cord is connected to the switch and the power outlet. Possible Cause & Solution: 1. Power Not Turned On - Make sure the power of the switch is turned on.
- Page 26 ™ Signamax 065-7030Q 16-Port QoS Switch Power LED Failure Symptom: Power LED fails after running for a while. Possible Cause & Solution: 1. Loose Power Connection - Check if the power connection is loose. Make sure the connection is firmly made.
- Page 27 ™ Signamax 065-7030Q 16-Port QoS Switch No Connectivity to the Data Terminal Equipment Symptom: Link LED does not come up when the connection is established; the switch cannot communicate with the directly connected computers or network segment. Possible Cause & Solution: 1.
- Page 28 ™ Signamax 065-7030Q 16-Port QoS Switch - If the Link LED is not on and the cabling is intact, then reset the switch by pressing the reset button. - After resetting, if the switch still cannot communicate with other segments of the network, contact our authorized reseller then.
- Page 29 ™ Signamax 065-7030Q 16-Port QoS Switch No Connectivity to Certain Nodes on the Network Symptom: A DTE connected to the switch cannot send or receive information from certain segments on the network or across to another LAN or WAN. Possible Cause & Solution: 1.
