  • Page 1 R718PQA Model： Wireless Occupancy and Door Sensor Wireless Occupancy and Door Sensor R718PQA User Manual...

  • Page 2: Table Of Contents

    Table of Content 1. Introduction....................................................2 2. Appearance....................................................2 3. Main Features...................................................2 4.Set up Instruction..................................................3 5. Data Report....................................................4 6. Disabletime and Detectiontime..............................................6 7. Installation....................................................6 8.Important Maintenance Instruction............................................6...

  • Page 3: Introduction

    Introduction R718PQA is a long-range wireless occupancy and door sensor for Netvox Class A type devices based on LoRaWAN open protocol. LoRa Wireless Technology: LoRa is a wireless communication technology dedicated to long distance and low power consumption. Compared with other communication methods, LoRa spread spectrum modulation method greatly increases to expand the communication distance.

  • Page 4: Set Up Instruction

    4.Set up Instruction On/Off Insert batteries. Power on (users may need a flat blade screwdriver to open) Turn on Press and hold the function key for 3 seconds till the green indicator flashes once. Turn off Press and hold the function key for 5 seconds till green indicator flashes for 20 times. (Restore to factory setting) Power off Remove Batteries.

  • Page 5: Data Report

    R718PQA default Max Interval = 15min, Min Interval = 15min (if there is special custom shipment, the setting is changed according to customer requirements) The data parsing reported by the device is referenced by the Netvox LoraWAN Application Command document and http://www.netvox.com.cn:8888/page/index...
  • Page 6 (2) Read device parameters Downlink: 0297000000000000000000 Device returns: 8297003C003C0100000000 (device current configuration parameter) Example#1 based on MinTime = 1 Hour, MaxTime= 1 Hour, Reportable Change i.e. BatteryVoltageChange=0.1V MaxTime MaxTime leeping(MinTime) leeping(MinTime) Wakes up and collects data Wakes up and collects data Wake up and collects data REPORTS 3.6V REPORTS 3.5V...

  • Page 7: Disabletime And Detectiontime

    6. Disabletime and Detectiontime IRDisableTime is the sampling period while IRDetectionTime is detecting period. Both IRDisableTime and IRDetectionTime are 30 seconds in default. To save power, IR detection will be turned off for first 70% of IRDisableTime and turned on for rest 30% of IRDisableTime. ...
