NANLITE Forza 300B II User Manual page 40

⑭
WELDING
WELDING setting: rotate the "right knob" to select DIM, CCT, G/M, SPEED (Range: 1...100) or
PAUSE (ON/OFF), and rotate the "left knob" to set the corresponding parameters.
EFFECT MODE
CH: 512
EFFECT: WELDING
DIM: 100%
CCT: 5600K GM: 0
SPEED: 50
PAUSE: OFF
Rotate the "right knob" to select DIM, CCT, G/M, SPEED or PAUSE.
EFFECT MODE
CH: 512
EFFECT: WELDING
DIM: 100%
CCT: 5600K GM: 0
SPEED: 50
PAUSE: OFF
Rotate the "left knob" to set the corresponding parameters.
NOTE: When the PAUSE is on, the welding effect will pause.
Lighting effects and additional functionality will be probably updated with later firmware version.
·
Detailed information is subject to the instruction of firmware function.
SMART
SMART
EFFECT MODE
CH: 512
EFFECT: WELDING
DIM: 100%
CCT: 5600K GM: 0
SPEED: 50
PAUSE: OFF
SMART
EFFECT MODE
CH: 512
EFFECT: WELDING
DIM: 99%
CCT: 5600K GM: 0
SPEED: 50
PAUSE: OFF
SMART
39
