Stakka - Guestbed Frame
Assembly Instructions
Dimensions
Width - 98.8cm
Depth - 201.4cm
Height - 50.3cm
Important –
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, c a l l t h e
- Please keep for future reference
Customer Helpline: 03456 400 800
475/9955
497/0909
Issue 1 - 15/10/15
Advertisement
Related Manuals for Argos Stakka 475/9955
Summary of Contents for Argos Stakka 475/9955
- Page 1 Stakka - Guestbed Frame Assembly Instructions - Please keep for future reference 475/9955 497/0909 Dimensions Width - 98.8cm Depth - 201.4cm Height - 50.3cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, c a l l t h e Customer Helpline: 03456 400 800 Issue 1 - 15/10/15...
- Page 2 Safety and Care Advice Important – Please read these instructions fully before starting assembly Check you have all the This product has been produced We do not from natural timber; you may recommend the components and tools listed on pages 2 and 3. notice some variation in the grain use of power and colour of different component...
- Page 3 Components - Panels Please check you have all the panels listed below Left foot x 4 ( 22.0 x 5.7cm) Right foot x 4 ( 22.0 x 5.7cm) Rail x 4 ( 90.0 x 13.8cm) Slats x 24 ( 91,0 x 7.0cm) Side rail x 4 ( 190,0 x 11.0cm)
- Page 4 Components - Fittings If you have damaged or missing components, call the Customer Helpline: 03456 400 800 Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required. Wooden dowel x 24 4.0 x 35mm Screw x 48 1/4 x 100mm Bolt x 8...
- Page 5 Assembly Instructions Step1 Insert wooden dowels into rails and side rails Step2 Attach left feet and right feet to rails using bolts and allen key Make sure feet are positioned as shown.
- Page 6 Assembly Instructions Step3 With help, fit one side rail to the assembled frame. Insert half moon nut as shown, then fix parts using bolts and allen Repeat step 3 for the other side rail. Step4 With help, fit side rails to another assembled frame.
- Page 7 Assembly Instructions Step5 Assembling slats Please fix the first slat next to the headboard/footboard and work towards the middle of the bed using spacer shown to ensure correct spacing. Fix slats to one side first using screws After, fix all the slats to the other side by pushing the rail against the slats if...
- Page 8 Assembly Instructions Step6 Stack one bed above the other. Make sure the rails of the bed at the bottom are inside the grooves of the feet. Assembly is complete. If you need help or have damaged or missing parts, c a l l t h e Customer Helpline: 03456 400 800...
