Tolga - Desk 2drws
Assembly Instructions
Dimensions
Width - 90cm
Depth - 49,2cm
Height - 68cm
Important
– Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, please visit: www.argos-support.co.uk
or email: Help@ClickSpares.co.uk (quoting your original order number)
Alternatively, call the Spares Helpline on: 0370 112 1928
For any other queries please contact the Customer Helpline on: 0345 640 2020
- Please keep for future reference
25kg
482/4495 PINK
473/9920 OAK
453/6927 BLUE
Tip : To prevent damage,
we recommend that you
build your unit on the
carton(s) it was packed in.
482/4495
473/9920
453/6927
Issue 1 - 04/11/15
Advertisement
Related Manuals for Argos 482/4495
Summary of Contents for Argos 482/4495
- Page 1 Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, please visit: www.argos-support.co.uk or email: Help@ClickSpares.co.uk (quoting your original order number) Alternatively, call the Spares Helpline on: 0370 112 1928...
-
Page 2: Handy Hints
Safety and Care Advice Important – Please read these instructions fully before starting assembly • Check you have all the • During assembly do not stand • To reduce components and tools listed or put weight on the product, the likelihood of on the following pages. - Page 3 Components - Panels For damaged or missing parts, please visit: www.argos-support.co.uk or email: Help@ClickSpares.co.uk Please check you have all the panels listed below Top x 1 Back x 1 (900 x 492 x 34mm) (452 x 331 x 2.5mm) P8506...
-
Page 4: Tools Required
Components - Fittings For damaged or missing parts, please visit: www.argos-support.co.uk or email: Help@ClickSpares.co.uk Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required. - Page 5 Assembly Instructions Step - 1 Insert large locking nuts C into plinth #. Make sure the ‘arrow’ on locking nuts C points towards the hole in the edge of #. Put drop of glue N into the 2 holes of plinth #. Put dowels H into the holes of plinth #.
- Page 6 Assembly Instructions Step - 3 Attaching runners a: Fix runner left part A Q on upright 4 as shown usesing 10mm fixing screw drawer E into upright 4. Note: look carreful for the right postion. Insert large locking nuts C Finished into upright 4.
- Page 7 Assembly Instructions Step - 4 Insert large locking nuts C into shelf 6. Make sure the ‘arrow’ on locking nuts C points towards the hole in the edge of 6. Step - 5 Attaching panels Finished Put drop of glue N into the front edge 2 holes of upright 4 and right side 5 on the bottom...
- Page 8 Assembly Instructions Step - 6 Insert large locking nuts C into segment 7. Make sure the ‘arrow’ on locking nuts C points towards the hole in the edge of 7. Step - 7 Insert large locking nuts C into left side 3. Make sure the ‘arrow’...
- Page 9 Assembly Instructions Step - 9 Insert nylon plug L into top 1. Screw 24mm locking screw A into the nylon plug L and into top 1. Note: Insert 24mm locking screw A as far as shown. Do not over tighten. Finished front edge Step - 10...
- Page 10 Assembly Instructions Step - 11 Fitting back panel Attach back 2 to the back with the coloured surface facing the inside using nails G. Use nail holder M to hold the nails G vertical and at correct distance as you secure the back 2. Nails G should be spaced about 150mm apart.
- Page 11 Assembly Instructions Step - 13 Screw 24mm locking screw A into drawer front Note: Insert 24mm locking screw A as far as shown. Do not over tighten. Step - 14 Position drawer onto drawer front @. Use a screwdriver to turn locking nuts clockwise to lock.
- Page 12 Assembly Instructions Step - 15 Turn over drawer. Fix runner left part B P on left drawer side 9 as shown using 12,5mm pozi screw D. Fix runner right part B R on right drawer side ! as shown using 12,5mm pozi screw D.
- Page 13 Assembly Instructions Step - 17 Position L-bracket J under top 1 as shown, fix using screw F. Note: there is no pre-drilled hole for screw F. Use S to fix on the wall, please see last page for more information. Use peg K to square your furniture.
-
Page 14: A Guide To - Wall Mounting & Fixings
A Guide to - Wall Mounting & Fixings Important: When drilling into walls always Important note: check that there are no hidden wires or pipes etc. If plastic wall plugs Make sure that the screws and wall plugs being used are supplied with your are suitable for supporting your unit.
