Prilux STAR FLAKE MINI Manual page 6

ASSEMBLY/REPAIR OF THE SEGMENT WITH SPLICE FLEXILIGHT
1
Locate the section to repair.
3
Insert a new connector metal ente-
ring through wire pin inside the holes
of the internal wires.
WARNING!
MAKE SURE THAT THE POLARITY AND
THE POWER DIRECTION ARE CO-
RRECT.
5
Proceed to join the two ends of the
wire through the connector.
2
Cut a piece of new wire and seal
the ends with silicone.
4
Enter a shrink in the wire´s side for its
subsequent sealing.
6
Introduce the shrink on the joint of
the wo wire´s sections.
