PARTS LIST

ITEM QTY REFERENCE
Optional EMI Filter Components
36 0 C1, C27
37 0 C2, C28
38 4 C5, C6, C30, C45
39 2 C15, C43
40 0 C19-C21, C47, C48
41 1 C49
42 3 FB4, FB9, FB10
43 0 FB5
44 2 L1, L3
45 2 R7, R41
46 0 CL1-CL6
47 0 SH1
Optional Electrical Components
48 0 C17, C18, C25, C41,
C46, C50, C51
49 0 C12, C13, C16, C37,
C39, C40, C44
50 0 C24
51 0 D2, D3, D5, D6
52 0 FB1-FB3, FB6-FB8
53 0 Q1
54 0 R3, R6, R12, R19-
R22, R25, R32,
R37, R38, R44-R46,
R50, R51, R59
55 0 R48
Hardware: For Demo Board Only
56 10 E1-E4, E8-E13
57 5 E14-E18
58 2 J1, J2
59 4 MP1-MP4
DEMO MANUAL EVAL-LT8355-1-AZ
PART DESCRIPTION
CAP ., OPTION, 0402
CAP ., OPTION, 1206
CAP ., 10μF, X7R, 25V, 10%, 1210, AEC-Q200
CAP ., 0.1μF, X7S, 100V, 10%, 0603, AEC-Q200
CAP ., OPTION, 0603
CAP ., 0.1μF, X7R, 50V, 10%, 0603, AEC-Q200
IND., 330Ω AT 100MHz, FERRITE BEAD, 25%, 1.8A,
80mΩ, 0805, 1LN
IND., FERRITE BEAD, OPT, 0805
IND., 8.2μH, PWR, SHIELDED, 20%, 8A, 26.4mΩ,
6.56mm × 6.36mm, XAL6060, AEC-Q200
RES., 10Ω, 5%, 1/10W, 0603, AEC-Q200
OPTION, WE-SHC CABINET CLIP
6.5mm × 0.8mm × 1.27mm
OPTION, WE-SHC SHIELDIY 61.5mm × 61.5mm
CAP ., OPTION, 0402
CAP ., OPTION, 1210
CAP ., OPTION, ALUM. ELECT., SMD
DIODE, OPTION, SOD-323F
IND., OPTION, FERRITE BEAD, 1210
XSTR., OPTION, PNP , SOT-23
RES., OPTION, 0402
RES., OPTION, 0603
TEST POINT, TURRET, 0.094" MTG. HOLE, PCB 0.062" THK
TEST POINT, TURRET, 0.064" MTG. HOLE, PCB 0.062" THK
CONN., BANANA JACK, FEMALE, THT, NON-INSULATED,
SWAGE, 0.218"
STANDOFF , NYLON, SNAP-ON, 0.50"
MANUFACTURER/PART NUMBER
TDK, CGA6P1X7R1E106K250AC
TDK, CGA3E3X7S2A104K080AB
TDK, CGA3E2X7R1H104K080AA
TAIYO YUDEN, FBMH2012HM331-T
COILCRAFT, XAL6060-822MEC
VISHAY, CRCW060310R0JNEA
WURTH, 369 000 00
WURTH, 360002
MILL-MAX, 2501-2-00-80-00-00-07-0
MILL-MAX, 2308-2-00-80-00-00-07-0
KEYSTONE, 575-4
KEYSTONE, 8833
